PD-16A040
Vishay Dale
Plasma Panel Displays
16 Character, 16 Segment Alphanumeric Display
with .400" [10.16mm] High Characters
FEATURES
• 50 foot lamberts brightness
• Designed for multiplexed operation
• Edgeboard connection
• Low power consumption
MAXIMUM RATINGS*
Peak Applied Voltage:
250 volts.
Operating Temperature:
0 to + 55°C.
Storage Temperature:
- 55°C to + 85°C.
Altitude:
70,000 feet.
*Values beyond which the life of the device may be reduced.
DIMENSIONS
in inches [millimeters]
7.00
±
.040
[177.80
±
1.02]
Character #1
6.595 [167.51]
Ref.
6.185 [157.10]
Ref.
.294
[7.47]
Max.
.400
±
.005
[10.16
±
.127]
.550 [13.97]
Max. Dia.
1.38
±
.040
1.135
[35.05
±
1.02][28.83] Ref.
.250
±
.040
[6.35
±
1.02]
.930
±
.062
[23.62
±
1.57]
.675 [17.15]
Ref.
.060
±
.005
[1.52
±
.127]
Typ.
Pad #1
68 Spaces
@ .100 [2.54]
= 6.80 [172.72]
Tolerance
Non-Accumulative
6.475 [164.47]
Ref.
.125
±
.015
[3.18
±
.381]
.120 + .010
- .005
[3.05 + .254
- .127]
.550
[13.97]
Max.
3.50
±
.062
[88.90
±
1.57]
SEGMENT DESIGNATION
A
I
H
P
G
O
N
F
M
E
Decimal
Point
ORDERING INFORMATION
B
J
K
L
C
DESCRIPTION
D
PART NUMBER
Display with Edgeboard Type Connection ............................................................... PD-16A040
www.vishay.com
2
Document Number: 37031
Revision 08-Nov-00
