PolySwitch®
PTC Devices
Overcurrent Protection Device
PRODUCT: RUEF135
DOCUMENT: SCD25171
REV LETTER: H
REV DATE: JULY 26,2016
PAGE NO.: 1 OF 2
Specification Status: Released
Maximum Electrical Rating at 20°C
30 V
DC
/100 A
DC
30 V
AC
/70 A
RMS
Insulating Material:
Cured, Flame Retardant Epoxy Polymer
meets UL94 V-0 Requirements
Lead Material:
24 AWG Tin Plated Copper Clad Steel
Marking:
Manufacturer’s Mark
U135
and Part Identification
Lot Identification
TABLE I. DIMENSIONS:
A
mm:
in*:
MIN
--
MAX
8.9
MIN
--
B
MAX
13.5
(0.53)
MIN
4.3
(0.17)
C
MAX
5.8
(0.23)
MIN
7.6
(0.30)
D
MAX
--
--
MIN
--
--
E
MAX
3.0
(0.12)
--
(0.35)
--
*Rounded off approximation
CURRENT
RATINGS
TABLE II. PERFORMANCE RATINGS:
I HOLD
TIME TO
TRIP
RESISTANCE
ONE-HOUR
POST-TRIP
RESISTANCE
STANDARD TRIP
OHMS
AT 20°C
MAX
0.13
TRIPPED POWER
DISSIPATION
AMPS
20°C
HOLD
1.35
AMPS AT
20°C
HOLD
TRIP
1.35
2.70
SECONDS AT
20°C, 6.75.A
MAX
7.3
OHMS
AT 20°C
MIN
MAX
0.04
0.08
WATTS AT
20°C
NOMINAL
0.80
WATTS AT
20°C
MAX
1.25
Agency Recognitions:
Reference Documents:
Precedence:
Effectivity:
CAUTION:
ROHS Compliant
UL, CSA, TUV, CQC
PS300
This specification takes precedence over documents referenced herein.
Reference documents shall be the issue in effect on the date of invitation for bid.
Operation beyond the rated voltage or current may result in rupture, electrical arcing or flame.
ELV Compliant
Pb-Free
Halogen Free*
Materials Information
HF
* Halogen Free refers to: Br≤900ppm, Cl≤900ppm,Br+Cl≤1500ppm.
© 2016 Littelfuse,Inc
Specifications are subject to change without notice.
Revised July 26 2016
littelfuse.com
PolySwitch®
PTC Devices
Overcurrent Protection Device
PRODUCT: RUEF135
DOCUMENT: SCD25171
REV LETTER: H
REV DATE: JULY 26,2016
PAGE NO.: 2 OF 2
Information furnished is believed to be accurate and reliable. However, users should independently evaluate the suitability of and test each product selected for their
own applications. Littelfuse products are not designed for, and shall not be used for, any purpose (including, without limitation, military, aerospace, medical, lifesaving,
life-sustaining or nuclear facility applications, devices intended for surgical implant into the body, or any other application in which the failure or lack of desired
operation of the product may result in personal injury, death, or property damage) other than those expressly set forth in applicable Littelfuse product documentation.
Warranties granted by Littelfuse shall be deemed void for products used for any purpose not expressly set forth in applicable Littelfuse documentation. Littelfuse shall
not be liable for any claims or damages arising out of products used in applications not expressly intended by Littelfuse as set forth in applicable Littelfuse
documentation. The sale and use of Littelfuse products is subject to Littelfuse Terms and Conditions of Sale, unless otherwise agreed by Littelfuse.
© 2016 Littelfuse,Inc
Specifications are subject to change without notice.
Revised July 26 2016
littelfuse.com
