F-209-2
SFSD–20–30–H–05.00–D–NDS
SFSDT–10–28–H–05.00–DR–NUS
SFSS–10–30–H–05.00–D–NUS
SOCKET CABLE ASSEMBLY
SPECIFICATIONS
For complete specifications
see www.samtec.com?SFSS,
www.samtec.com?SFSD,
www.samtec.com?SFSDT or
www.samtec.com?SFSST
Insulator Material:
Black LCP
Contact Material:
BeCu
Plating:
Au over 50µ" (1,27µm) Ni
Operating Temp Range:
-55°C to +80°C (PVC)
-55°C to +125°C (*Teflon
®
)
Voltage Rating:
275 VAC (PVC)
235 VAC (*Teflon
®
)
Wire:
28 or 30 AWG
RoHS Compliant:
Yes
CURRENT RATING
AMBIENT
SFSD/TFC
TEMP
3.7A
20°C
3.4A
40°C
2.9A
60°C
1.9A
95°C
6 POSITIONS (2x3)
28 AWG POWERED
SFSS, SFSD
SERIES
Mates with:
TFM, TFC
Single or
Doubled
Ended
28 or 30
AWG
™
(1,27mm)
.050"
pitch
Retention Latch
for Single or
Double row
TYPE
STRIP
POSITIONS
PER ROW
WIRE
GAUGE
PLATING
OPTION
ASSEMBLED
LENGTH
END
OPTION
END 2
OPTION
Requires
–D or –DR
(End No. 1
Notch Up).
–SR/–DR
APPLICATIONS
When Mated to TFM-WT
Terminal/Housing Retention
Min
Max
Avg
Min
Max
Avg
(22,25N) 5.0 lb
(26,52N) 5.96 lb
(24,34N) 5.47 lb
(20,47N) 4.6 lb
(36,49N) 8.2 lb
(29,95N) 6.73 lb
SFSS
= Single
Row
PVC
Cable
–05,
–07, –10,
–15, –20,
–25, –30
(Call Samtec for
other sizes)
–30
= 30 AWG
–H
= 30µ"
(0,76µm)
Gold on
contact,
Gold Flash
on balance
–“XX.XX”
= Assembled
Length in
Inches
(76,20mm)
03.00" min. for
–S end option
(82,60mm)
03.25" min. for
–D end option
–S
= Single Ended
= Double Ended
(End No. 2
notch options
required)
–28
= 28 AWG
–D
–NUS
= Notch up,
straight
SFSST
= Single
Row
*Teflon
®
Cable
No. of Positions x
(1,27) .050 +
(0,38) .015
Wire/Crimp Retention
–SR
= Single Ended
with Retention
Latch
–NDS
= Notch down,
straight
SFSD
= Double
Row
PVC
Cable
(6,35)
.250
(1,27)
.050
Notch End 1
(2,03)
.080
(5,08)
.200
–NUX
= Notch up,
crossed
(SFSD/
SFSDT only)
–DR
= Double Ended
with Retention
Latch
(End No. 2
notch options
required)
(1,65).065
Assembled
Length
± (3,18)
.125
APPLICATION
SPECIFIC OPTION
• Locking feature
available for mating to
the TFML Series
• Color coded cable
available (*Teflon
®
N/A)
• Other plating available
Call Samtec.
*Teflon
®
is a trademark
of Dupont.
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
SFSDT
= Double
Row
*Teflon
®
Cable
Assembled
Length
± (3,18)
.125
(11,18)
.440
(1,27)
.050
(6,32)
.249
–NDX
= Notch down,
crossed
(SFSD/
SFSDT only)
(2,86)
.113
(0,25)
.010
Notch
End 2
SFSD
–D–NUS
SFSS
–SR
WWW.SAMTEC.COM
140
