ECS-PEC33-FREQ-C-M

Description
PECL Output Clock Oscillator, 40MHz Min, 300MHz Max, ROHS COMPLIANT, MINIATURE, CERAMIC, SMD, 6 PIN
CategoryPassive components    oscillator
File Size239KB,2 Pages
ManufacturerECS
Websitehttp://www.ecsxtal.com/
Environmental Compliance
Download Datasheet Parametric View All

ECS-PEC33-FREQ-C-M Overview

PECL Output Clock Oscillator, 40MHz Min, 300MHz Max, ROHS COMPLIANT, MINIATURE, CERAMIC, SMD, 6 PIN

ECS-PEC33-FREQ-C-M Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerECS
Reach Compliance Codecompliant
Other featuresTRI-STATE; ENABLE/DISABLE; TAPE AND REEL
maximum descent time1 ns
Frequency Adjustment - MechanicalNO
frequency stability25%
JESD-609 codee4
Manufacturer's serial numberECS-PEC33
Installation featuresSURFACE MOUNT
Maximum operating frequency300 MHz
Minimum operating frequency40 MHz
Maximum operating temperature70 °C
Minimum operating temperature-20 °C
Oscillator typePECL
Output load50 OHM
physical size7.0mm x 5.0mm x 1.7mm
longest rise time1 ns
Maximum supply voltage3.465 V
Minimum supply voltage3.135 V
Nominal supply voltage3.3 V
surface mountYES
maximum symmetry45/55 %
Terminal surfaceGold (Au) - with Nickel (Ni) barrier
Low Voltage PECL
7 x 5 mm Footprint
Low Jitter
Pb Free/RoHS Compliant
ECS-PEC25/PEC33
SMD PECL OSCILLATOR
ECS-PEC25 (2.5V) and ECS-PECS33 (3.3V) miniature SMD
PECL oscillators. Ideal for low jitter applications.
OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS
ECS-PEC25 (+2.5V)
ECS-PEC33 (+3.3V)
PARAMETERS
Frequency Range
Operating Temperature
Storage Temperature
Supply Voltage
Frequency Stability *
Input Current
Stand-by Current
Output Symmetry
Rise and Fall Times
"0" level
"1" level
Output Load
Disable delay time
Enable/Startup time
RMS Jitter
Aging
CONDITIONS
MIN
40.0
0
-40
-50
+2.375
TYP
MAX
MIN
TYP
MAX
300.0
+70
+85
+125
+3.465
± 100
± 50
± 25
90
30
45/55
1
+1.745
UNITS
MHz
°C
°C
°C
VDC
ppm
ppm
ppm
mA
µA
%
ns
VDC
VDC
ns
ms
ps
ppm
Standard
Extended (N Option)
VDD
Option A
Option B
Option C
Pin 1 open or VIH
Pin 1 = VIL
@ 50% V
DD
level
20% VDD to 80% level
VOL
VOH
50Ω into V
DD
-2V
+2.5
300.0
40.0
+70
0
+85
-40
+125
-50
+2.625 +3.135
± 100
± 50
± 25
90
30
40/60
1
+1.195
+2.215
+3.3
+1.415
12 KHz to 20 MHz band
200
10
1
±5
200
10
1
±5
DIMENSIONS (mm)
Pin Connections
Pin #1
Pin #2
Pin #3
Pin #4
Pin #5
Pin #6
Tri-State
N.C.
Ground
Output
C-Output
V
DD
Tri-State Control Voltage
Pad 1
Open
VIH 70% VDD Min
VIL 30% VDD Max
Pad 4 & 5
Oscillation
Oscillation
No Oscillation
Figure 1) Top, Side and Bottom views
Figure 2) Suggested Land Pattern
Note: Internal crystal oscillation to be halted
(Pin #1=VIL)
PART NUMBERING GUIDE: Example ECS-PEC33-1000-B-N
ECS
-
Series
-
Frequency Abbreviation -
1000 = 100.000 MHz
See Frequency
Abbreviations (Pg 2)
Stability
-
Temperature
Blank = 0 ~ +70°C
M = -20 ~ +70°C
N = -40 ~ +85°C
Fax: 913.782.6991
www.ecsxtal.com
PEC25 = +2.5V
PEC33 = +3.3V
A = ± 100 ppm
B = ± 50 ppm
C = ± 25 ppm
1105 South Ridgeview Road
Olathe, KS 66062
Phone: 913.782.7787
