mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Designed to IEC 60664-1
Designed to IEC 60664-1
Type
Type
without
mounting flange
369
Additional Centerline
Type 369
Type 379
Voltage
379
300 V - centerline
600 V - centerline
8A
16 - 28 AWG
3 lbs. - in
7 mm
≤
5 mΩ per circuit
3.81 mm
7.62 mm
Voltage
with
mounting flange
Electrical Data
Electrical Data
300 V - centerline
600 V - centerline
8A
16 - 28 AWG
3 lbs. - in
7 mm
≤
5 mΩ per circuit
3.81 mm
7.62 mm
Headers that mate with
Type 369
Type 383
Type 382
Type 379
Type 393
Type 392
Page H-11
Page H-12
Page H-11
Page H-12
Current
Wire range
Screw torque
Wire strip length
Contact resistance
Current
Wire range
Screw torque
Wire strip length
Contact resistance
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
black
brass, nickel plated
copper alloy, tin plated
M2, steel
nickel over copper plating
2 to 24 - centerline 3.81 mm
2 to 12 - centerline 7.62 mm
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
black
brass, nickel plated
copper alloy, tin plated
M2, steel
nickel over copper plating
2 to 24 - centerline 3.81 mm
2 to 12 - centerline 7.62 mm
Color
Terminal
Wire protector
Screw
Pole sizes
Color
Terminal
Wire protector
Screw
Pole sizes
Additional material data - pages DA-3 to DA-5
Additional material data - pages DA-3 to DA-5
Dimensions (mm)
Dimensions (mm)
L = (circuits - 1) x centerline + 4.6
L = (circuits - 1) x centerline + 14.2
Part Numbers
Type 369
Complete the part number
by adding the pole size.
centerline 3.81 mm
Part Numbers
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
02 03 04 05 06 07 08
09 10 11 12
Type 379
Complete the part number
by adding the pole size.
centerline 3.81 mm
Part No.
313691
Type 369
centerline 7.62 mm
Part No.
313791
Type 379
centerline 7.62 mm
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
02 03 04 05 06 07 08
09 10 11 12
Part No.
313692
Part No.
313792
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
DB-3
