3.2 x 2.5 mm
Precision TCXO
In Stock at Digi-Key
Description:
2111 Comprehensive Drive
2111 Comprehensive Drive
Aurora, Illinois 60505
Aurora, Illinois 60505
Phone: 630- 851- 4722
Phone: 630- 851- 4722
Fax: 630- 851- 5040
Fax: 630- 851- 5040
www.conwin.com
www.conwin.com
US Headquarters:
630-851-4722
European Headquarters:
+353-61-472221
Features:
Model: D32G
TCXO
3.3 Vdc Operation
Clipped Sinewave Output
Frequency Stability:
±0.50
ppm
Temperature Range: -30 to 85°C
Low Jitter: < 1 ps RMS
3.2 x 2.5 mm SMT Package
Tape and Reel Packaging
RoHS Compliant / Lead Free
The Connor-Winfield D32G is a 3.2
x 2.5 mm, 3.3 V Clipped Sinewave,
Surface Mount, Temperature
Compensated Crystal Oscillator
(TCXO) designed for applications
requiring tight frequency stability in
a very small package. The RoHS
compliant surface mount package is
designed for high-density mounting
and is optimum for mass production.
Absolute Maximum Ratings
Parameter
Storage Temperature
Supply Voltage (Vcc)
Minimum
-55
-0.5
Nominal
-
-
Maximum
85
6.0
Units
°C
Vdc
Notes
Operating Specifications
Parameter
Center Frequency: (Fo)
Frequency Calibration @ 25 °C
Frequency Stability
Vs. Temperature:
VS. Supply Voltage:
VS. Load:
Static Temperature Hysteresis:
Aging per Year
Freq. Shift Due to Solder Reflow:
Operating Temperature Range:
Supply Voltage (Vcc) ±5%
Supply Current (Icc)
Period Jitter
Integrated Phase Jitter
SSB Phase Noise at 10Hz offset
SSB Phase Noise at 100Hz offset
SSB Phase Noise at 1KHz offset
SSB Phase Noise at 10KHz offset
SSB Phase Noise at 100KHz offset
Start-up Time -
Minimum
-
-1.0
16.368, 19.2 or 26.0
-
-
-
-
-
-
-
-
3.3
-
3
0.5
-80
-110
-130
-145
-145
-
Nominal
Maximum
-
1.0
Units
MHz
ppm
Notes
1
2
±5%
±5%
Absolute, 3
4
-0.50
-0.025
-0.025
-
-1.0
-1.0
-30
3.135
-
-
-
-
-
-
-
-
-
0.50
0.025
0.025
0.40
1.0
1.0
85
3.465
2.0
5
1.0
-
-
-
-
-
5
ppm
ppm
ppm
ppm
ppm
ppm
°C
Vdc
mA
ps rms
ps rms
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
ms
5
Clipped Sinewave Output Characteristics
Load (CL)
-
Output Voltage (High)
Package
Parameter
Minimum
1.0
10 pF // 10 KOhm
-
Nominal
Maximum
-
Units
V peak to peak
Notes
6
7
Package Characteristics
Hermetically sealed ceramic package and metal cover
Ordering Information
D32G-016.368M*, D32G-019.2M* or D32G-026.0M*
* For the tape and reel option, add -T to the end of the part number. Example: D32G-016.368M-T
Notes:
1. Initial calibration @ 25°C. Specifications at time of shipment after 48 hours of operation.
2
.
Frequency stability vs. change in temperature. [±(Fmax - Fmin)/2.Fo].
3
.
Frequency change after reciprocal temperature ramped over the operating range. Frequency measured before and after at 25°C.
4. Within two hours after reflow
5. BW = 12 KHz to 20 MHz.
6. Output is DC coupled. Load capacitor, load resistor, coupling capacitor and by pass capacitors are required components to
insure proper operation of this TCXO.
7. For best performance it is recommended that the circuit connected to this output should have an equivalent input capacitance
of 10pF.
Specifications subject to change without notice. All dimensions in inches. © Copyright 2011 The Connor-Winfield Corporation
Bulletin
Page
Revision
Date
TX240
1 of 2
05
19 Dec 2011
2111 Comprehensive Drive
Aurora, Illinois 60505
Phone: 630- 851- 4722
Fax: 630- 851- 5040
www.conwin.com
Environmental Characteristics
Vibration:
Vibration per Mil Std 883E Method 2007.3 Test Condition A
Shock:
Mechanical Shock per Mil Std 883E Method 2002.4 Test Condition B.
Soldering Process;
RoHS compliant lead free. See soldering profile on page 2.
Pad Connections
1:
2:
3:
4:
N/C
Ground
Output
Supply Voltage (Vcc)
Package Layout
0.098
(2.50mm)
0.043 Max.
(1.10mm Max.)
0.039
(1.00mm)
Suggested Pad Layout
0.0325
(0.83mm)
0.037
(0.94mm)
0.037
(0.94mm)
Output Waveform
19.2 8J
D32G
0.128
(3.20mm)
0.025
(0.64mm)
0.121
0.071 (3.08mm)
(1.80mm)
3
Top
View
2
0.035
(0.89mm)
0
0.0625
(1.59mm)
1
0.035
(0.89mm)
Pin 1
0.027
(0.69mm)
4
200 mV/Div
0.094
(2.38mm)
Dimensional Tolerance:
+/-005 (+/-0.127mm)
Keep Out Area*
* Do not route any traces in the keep out area.
It is recommended the next layer under the
keep out area is to be ground plane.
Typical Phase Noise Plot
Model D32G-19.2MHZ
Test Circuit
Vcc
Supply
Voltage
AC Coupling
Capacitor *
4
3
10Kohm *
Output
10 pF *
0.1 uF
Bypass *
10 nF
Bypass *
1
N/C
2
* Required components to insure proper operation.
Tape and Reel Information
Solder Profile
Temperature
260°C
220°C
180°C
150°C
120°C
260°C
Direction of Feed (Customer)
0.157
(4.0mm)
0.079
(2.0mm)
0.039
(1.0mm) DIA
0.069
(1.75mm)
0.216
(5.5mm) 0.472
(12mm)
0.039
(1.0mm) DIA
0.512
(13mm)
0.051
(1.3mm)
0.354
(9mm)
0.051
(1.3mm)
19.2 8J
D32G
0.079
(2mm) 7.09
(180mm)
2.36
(60mm)
0
10 s
Up to 120 s
60 to 90 s
Typical
Typical
Meets IPC/JEDEC J-STD-020C
0.157
(4.0mm)
Bulletin
Page
Revision
Date
TX240
2 of 2
05
19 Dec 2011
Specifications subject to change without notice. All dimensions in inches. © Copyright 2011 The Connor-Winfield Corporation
