TCMM3Z2V7C: DescriptionZener Diode, 2.7V V(Z), 5%, 0.2W, Silicon, Unidirectional, ROHS COMPLIANT, PLASTIC, SIMILAR TO SC-90, 2 PIN; CategoryDiscrete semiconductor diode; File Size158KB，3 Pages; ManufacturerTak Cheong; Websitehttp://www.takcheong.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

TCMM3Z2V7C Overview

Zener Diode, 2.7V V(Z), 5%, 0.2W, Silicon, Unidirectional, ROHS COMPLIANT, PLASTIC, SIMILAR TO SC-90, 2 PIN

TCMM3Z2V7C Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Tak Cheong
Parts packaging code	SC-90
package instruction	R-PDSO-F2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JESD-30 code	R-PDSO-F2
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	2
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.2 W
Certification status	Not Qualified
Nominal reference voltage	2.7 V
surface mount	YES
technology	ZENER
Terminal surface	Matte Tin (Sn)
Terminal form	FLAT
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	5%
Working test current	5 mA

Preview

Download Datasheet

View All

SEM IC O N DU C TO R

200mW SOD-323 SURFACE MOUNT

Small Outline Flat Lead Plastic Package

Zener Voltage Regulators

Absolute Maximum Ratings

Symbol

P

D

T

STG

T

OPR

Power Dissipation

Storage Temperature Range

Operating Temperature Range

T

A

= 25°C unless otherwise noted

Value

200

-65 to +150

Units

mW

°C

SOD-323 Flat Lead

Parameter

These ratings are limiting values above which the serviceability of the diode may be impaired.

Specification Features:

Wide Zener Voltage Range Selection, 2.0V to 75V

VZ Tolerance Selection of ±5% (C Series)

Flat Lead SOD-323 Small Outline Plastic Package

Surface Device Type Mounting

Moisture Sensitivity Level 1

Clip Bonding Construction, Good Thermal Capability

RoHS Compliant

Matte Tin(Sn) Lead Finish

Band Indicates Cathode

ELECTRICAL SYMBOL

Cathode

Anode

Electrical Characteristics

Device

Type

TCMM3Z2V0C

TCMM3Z2V2C

TCMM3Z2V4C

TCMM3Z2V7C

TCMM3Z3V0C

TCMM3Z3V3C

TCMM3Z3V6C

TCMM3Z3V9C

TCMM3Z4V3C

TCMM3Z4V7C

TCMM3Z5V1C

TCMM3Z5V6C

TCMM3Z6V2C

TCMM3Z6V8C

TCMM3Z7V5C

TCMM3Z8V2C

TCMM3Z9V1C

TCMM3Z10VC

TCMM3Z11VC

TCMM3Z12VC

TCMM3Z13VC

TCMM3Z15VC

TCMM3Z16VC

Device

Marking

Z:

Z+

Z0

Z1

Z2

Z3

Z4

Z5

Z6

Z7

Z8

Z9

ZA

ZB

ZC

ZD

ZE

ZF

ZG

ZH

ZJ

ZK

ZL

T

A

= 25°C unless otherwise noted

V

Z

@ I

ZT

(Volts)

Min

1.90

2.09

2.28

2.57

2.85

3.14

3.42

3.71

4.09

4.47

4.85

5.32

5.89

6.46

7.11

7.79

8.65

9.50

10.45

11.40

12.35

14.25

15.20

Nom

2.0

2.2

2.4

2.7

3.0

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

7.5

8.2

9.1

10

11

12

13

15

16

Max

2.10

2.31

2.52

2.84

3.15

3.47

3.78

4.10

4.52

4.94

5.36

5.88

6.51

7.14

7.86

8.61

9.56

10.50

11.55

12.60

13.65

15.75

16.80

I

ZT

(mA)

5

Z

ZT

@ I

ZT

(Ω)

Max

100

95

90

80

60

40

10

15

20

25

30

40

I

ZK

(mA)

1

Z

ZK

@ I

ZK

(Ω)

Max

600

564

470

451

376

141

75

94

141

160

188

I

R

@ V

R

(µA)

Max

120

45

18

9

4.5

2.7

1.8

0.9

2.7

1.8

0.9

0.63

0.45

0.18

0.09

0.045

V

R

(Volts)

0.5

0.7

1

2

4

5

6

7

8

10.5

11.2

June 2007, Revision C

Page 1

TCMM3Z2V0C through TCMM3Z75VC

TAK CHEONG

®
