Data Sheet
10 Amp SUPER FAST RECOVERY
POWER RECTIFIERS
Mechanical Dimensions
JEDEC
TO-220AB
Description
UF10C05.....10C60
1
3
1
3
2
CASE
Double Suffix D
1
2
CASE 3
Common Anode Suffix A
2
CASE
Common Cathode Suffix C
Features
n
LOW FORWARD VOLTAGE
n
HIGH SURGE CAPABILITY
n
SUPER FAST RECOVERY TIME
n
MEETS UL SPECIFICATION 94V-0
UF10C05....UF10C60
Maximum Ratings
Peak Repetitive Reverse Voltage...V
RRM
Working Peak Reverse Voltage...V
RWM
DC Blocking Voltage...V
DC
RMS Reverse Voltage...V
R(rms)
Average Forward Rectified Current...I
F(av)
(Per Leg)
T
C
= 100°C @ Rated V
DC
( Total)
Repetitive Peak Forward Surge Current...I
FM
@ Rated V
DC
, Square Wave, 20 kHz, T
C
= 100°C
Non-Repetitive Peak Forward Surge Current...I
FSM
@ Rated Load Cond., ½ Wave, Single Phase, 60Hz
Operating & Storage Temperature Range...T
J
, T
STRG
Electrical Characteristics, Per Diode Leg
Maximum Forward Voltage...V
F
@ I
F
= 5 Amps, PW = 300µs
Maximum DC Reverse Current...I
R
@ Rated DC Blocking Voltage
T
C
= 25°C
Units
50 100 200 300 400 500 600
05 100 200 300 400 500 600
05 100 200 300 400 500 600
35
70 140 210 280 350 420
5
10
10
Volts
Volts
Volts
Volts
Amps
Amps
Amps
Amps
°C
100
-50 to 150
---- 0.95 ---- ---1.3---- ---1.5 ----
Volts
T
C
=125°C
T
C
= 25°C
500
10
µAmps
µAmps
ns
Maximum Reverse Recovery Time...t
RR
I
F
= 0.5 Amp, I
R
= 1A, I
rr
= 0.25A
------35----- --------- 50 -----------
Data Sheet
10 Amp SUPER FAST RECOVERY
POWER RECTIFIERS
Non-Repetitive
Peak Forward Surge Current
Forward Current Derating Curve
10
8
6
4
2
0
2 5 5 0 7 5 100 125 150 175
Ambient Temperature (°C)
°
Typical Reverse Characteristics
Junction Capacitance (pF)
Peak Forward Surge Current (A)
Average Forward Current (A)
12
200
100
10
1
10
100
Number of Cycles @ 60 Hz
Typical Junction Capacitance
Reverse Current (µA)
µ
UF10C.20
UF10C60
UF10C.20
UF10C 40
UF10C060
UF10C 40
Reverse Voltage (V)
Reverse Voltage (V)
Reverse Recovery
Characteristics
Non-Inductive
50Ω
Ω
Ω
D.U.T 10Ω
1
Ω
Non-
Inductive
(-)
Pulse
Generator
Note 2
Typical Instantaneous
Forward Characteristics
Forward Current (A)
UF10C.20
(+)
(-)
+.5A
0A
-.25A
-1.0A
t
RR
Ratings at
25 Deg. C ambient
temperature
unless otherwise
specified.
1 cm
Single Phase Half
Wave, 60 Hz
Resistive or
Inductive Load.
For Capacitive
Load, Derate
Current by 20%.
25 VDC
Oscilliscope (+)
Note 1
Notes:
UF10C40..60
Forward Voltage (V)
1 . Rise Time = 7 ns Max.
Impedance = 1 megohm, 22 pF
2 . Rise Time = 10 ns Max.
Source Impedance = 50 Ohms
Time Base Set @ 50/100ns/cm
