TLE2064BMJB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> TLE2064BMJB

TLE2064BMJB: DescriptionQUAD OP-AMP, 5500uV OFFSET-MAX, 1.3MHz BAND WIDTH, CDIP14, CERAMIC, DIP-14; CategoryAnalog mixed-signal IC Amplifier circuit; File Size3MB，82 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

TLE2064BMJB Overview

QUAD OP-AMP, 5500uV OFFSET-MAX, 1.3MHz BAND WIDTH, CDIP14, CERAMIC, DIP-14

TLE2064BMJB Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	CERAMIC, DIP-14
Contacts	14
Reach Compliance Code	unknown
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.03 µA
Nominal Common Mode Rejection Ratio	82 dB
Maximum input offset voltage	5500 µV
JESD-30 code	R-CDIP-T14
Humidity sensitivity level	NOT SPECIFIED
Negative supply voltage upper limit	-19 V
Nominal Negative Supply Voltage (Vsup)	-5 V
Number of functions	4
Number of terminals	14
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Filter level	MIL-STD-883
Maximum seat height	5.08 mm
Nominal slew rate	3.4 V/us
Supply voltage upper limit	19 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	BIFET
Temperature level	MILITARY
Terminal surface	NOT SPECIFIED
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
total dose	MIL-STD-883 V
Nominal Uniform Gain Bandwidth	1300 kHz
width	7.62 mm

Preview

Download Datasheet

View All

D ts e t

aa h e

R c e t r lc r nc

o h se Ee to is

Ma u a t r dCo o e t

n fc u e

mp n n s

R c e tr b a d d c mp n ns ae

o h se rn e

o oet r

ma ua trd u ig ete dewaes

n fcue sn i r i/ fr

p rh s d f m te oiia s p l r

uc a e r

o h r n l u pi s

o R c e tr waes rce td f m

r o h se

fr e rae r

te oiia I. Al rce t n ae

r nl P

l e rai s r

d n wi tea p o a o teOC

o e t h p rv l f h

P r aetse u igoiia fcoy

at r e td sn r n la tr

ts p o rmso R c e tr e eo e

e t rga

r o h se d v lp d

ts s lt n t g aa te p o u t

e t oui s o u rne

rd c

me t o e c e teOC d t s e t

es r x e d h

M aa h e.

Qu l yOv riw

e ve

• IO- 0 1

S 90

•A 92 cr ct n

S 1 0 et ai

• Qu l e Ma ua trr Ls (

ai d

n fcues it QML MI- R -

) LP F

385

•C a sQ Mitr

lay

•C a sVS a eL v l

p c ee

• Qu l e S p l r Ls o D sr uos( L )

ai d u pi s it f it b tr QS D

•R c e trsacic l u pir oD A a d

o h se i

r ia s p l t L n

me t aln u t a dD A sa d r s

es lid sr n L tn ad .

R c e tr lcrnc , L i c mmi e t

o h se Ee t is L C s o

tdo

s p ligp o u t ta s t f c so r x e t-

u pyn rd cs h t ai y u tme e p ca

t n fr u lya daee u loto eoiial

i s o q ai n r q a t h s r n l

s p l db id sr ma ua trr.

u pi

e yn ut

y n fcues

T eoiia ma ua trr d ts e t c o a yn ti d c me t e e t tep r r n e

h r n l n fcue’ aa h e a c mp n ig hs o u n r cs h ef ma c

a ds e ic t n o teR c e tr n fcue v rino ti d vc . o h se Ee t n

n p c ai s f h o h se ma ua trd eso f hs e ie R c e tr lcr -

isg aa te tep r r n eo i s mio d co p o u t t teoiia OE s e ic -

c u rne s h ef ma c ft e c n u tr rd cs o h r n l M p c a

t n .T pc lv le aefr eee c p r o e o l. eti mii m o ma i m rt g

i s ‘y ia’ au s r o rfrn e up s s ny C r n nmu

r xmu ai s

ma b b s do p o u t h rceiain d sg , i lt n o s mpetsig

y e a e n rd c c aa tr t , e in smuai , r a l e t .

z o

0 3 ohs E cr i , L . lRg s eevd 7 1 0 3

e e oc

T l r m r, l s v iw wrcl . m

o e n oe p ae it w . e c o

o ec

TLE206x, TLE206xA, TLE206xB

EXCALIBUR JFET INPUT HIGH OUTPUT DRIVE

µPOWER

OPERATIONAL AMPLIFIERS

SLOS193B − FEBRUARY 1997 − REVISED MAY 2004

2× Bandwidth (2 MHz) of the TL06x and

TL03x Operational Amplifiers

Low Supply Current . . . 290

µA/Ch

Typ

On-chip Offset Voltage Trimming for

Improved DC Performance

High Output Drive, Specified into 100-Ω

Loads

Lower Noise Floor Than Earlier

Generations of Low-Power BiFETs

description

The TLE206x series of low-power JFET-input operational amplifiers doubles the bandwidth of the earlier

generation TL06x and TL03x BiFET families without significantly increasing power consumption. Texas

Instruments Excalibur process also delivers a lower noise floor than the TL06x and TL03x. On-chip zener

trimming of offset voltage yields precision grades for dc-coupled applications. The TL206x devices are

pin-compatible with other Texas Instruments BiFETs; they can be used to double the bandwidth of TL06x and

TL03x circuits or to reduce power consumption of TL05x, TL07x, and TL08x circuits by nearly 90%.

BiFET operational amplifiers offer the inherently-higher input impedance of the JFET-input transistors, without

sacrificing the output drive associated with bipolar amplifiers. This makes them better suited for interfacing with

high-impedance sensors or low-level ac signals. They also feature inherently better ac response than bipolar

or CMOS devices having comparable power consumption. The TLE206x family features a high-output-drive

circuit capable of driving 100-Ω loads at supplies as low as

5 V. This makes them uniquely suited for driving

transformer loads in modems and other applications requiring good ac characteristics, low power, and high

output drive.

Because BiFET operational amplifiers are designed for use with dual power supplies, care must be taken to

observe common-mode input voltage limits and output swing when operating from a single supply. DC biasing

of the input signal is required and loads should be terminated to a virtual ground node at mid-supply. Texas

Instruments TLE2426 integrated virtual ground generator is useful when operating BiFET amplifiers from single

supplies.

The TLE206x are fully specified at

±15

V and

5 V. For operation in low-voltage and/or single-supply systems,

Texas Instruments LinCMOS families of operational amplifiers (TLC- and TLV-prefixes) are recommended.

When moving from BiFET to CMOS amplifiers, particular attention should be paid to slew rate and bandwidth

requirements and output loading. The Texas Instruments TLV2432 and TLV2442 CMOS operational amplifiers

are excellent choices to consider.

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of

Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PRODUCTION DATA information is current as of publication date.

Products conform to specifications per the terms of Texas Instruments

standard warranty. Production processing does not necessarily include

testing of all parameters.



2004, Texas Instruments Incorporated

POST OFFICE BOX 655303

•

DALLAS, TEXAS 75265
