D Subminiature
Straight Solder Termination (Machined) — European PC Tails
Plug
Part Numbers
Shell Size
DE
DA
DB
DC
DD
Layout
9
15
25
37
50
Through Hole
DE9P-0L2-K87
DA15P-0L2-K87
DB25P-0L2-K87
DC37P-0L2-K87
DD50P-0L2-K87
Standoff #4-40 UNC
With Pushfit/Boardlock
DEE9P-0L2-K87-146
DAE15P-0L2-K87-146
DBE25P-0L2-K87-146
DCE37P-0L2-K87-146
DDE50P-0L2-K87-146
D*
Selection Guide
For Product Features, Specifications,
Materials and Finishes, see pages 2-3.
Reader’s Resource
For contact cavity arrangements,
see page 224.
For P.C. hole patterns, see page 274.
For panel cutouts, see page 221.
For hardware views (European),
see page 227.
Standoff M3 With
Pushfit/Boardlock
DEX9P-0L2-K87-146
DAX15P-0L2-K87-146
DBX25P-0L2-K87-146
DCX37P-0L2-K87-146
DDX50P-0L2-K87-146
Note: For performance class 2 add -A191. Example DA15P-OL2-A191-K87.
PC Tail
Modifier
OL2
OL4
X
±0,30
(.012)
5,20 (.205)
6,75 (.266)
Y
±0,30
(.012)
10,20 (.401)
11,80 (.465)
Engaging Face
DD Configuration
A
C
Ø 3,05 (.120)
B
POSITION 1
5,69 (.224)
2,84 (.112)
E
D
L
10°
Ø 0,60 (.024)
X
Y
2,84 (.112)
W
F
Dimensions
Shell Size
DE
DA
DB
DC
DD
A
±0,38
(.015)
30,81 (1.213)
39,14 (1.541)
53,04 (2.088)
69,32 (2.729)
66,93 (2.635)
B
±0,13
(.005)
16,92 (.666)
25,25 (.994)
38,96 (1.534)
55,42 (2.182)
52,81 (2.079)
C
±0,13
(.005)
24,99 (.984)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
61,11 (2.406)
D
±0,13
(.005)
8,36 (.329)
8,36 (.329)
8,36 (.329)
8,36 (.329)
11,07 (.436)
E
±0,38
(.015)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
15,37 (.605)
F
±0.25
(.010)
10,72 (.422)
10,72 (.422)
10,82 (.426)
10,82 (.426)
10,82 (.426)
W
±0,368
(.0145)
6,693 (.2635)
6,693 (.2635)
—
—
—
W
±0,41
(.016)
—
—
6,84 (.269)
6,84 (.269)
6,84 (.269)
L
±0,25
(.010)
0,76 (.030)
0,76 (.030)
0,99 (.039)
0,99 (.039)
0,99 (.039)
10
Dimensions are shown in mm (inch)
Dimensions subject to change
