Power Dividers
Features
•
•
•
•
•
•
Low Insertion Loss
High Isolation
Available in 2, 3,4, 6, and 8 Way Units
Low VSWR
Amplitude and Phase Balanced
Compact Size
Description
These coaxial dividers/combiners are offered in 2, 3, 4, 6, and 8 way configurations
and come standard with SMA connectors (type “N” shown). They are available in three
frequency bands from 1,000 MHz to 18,000 MHz and are capable of handling 10 Watts
of power into a matched load. Units can also be supplied with other connector types or
higher power handling capability.
Ordering Information
1000-4000 MHz
Part Number
Channels
Isolation
(dB)
20
20
20
20
20
Insertion
Loss (dB)
(maximum)
0.4
0.5
0.5
0.6
0.6
Amplitude
Balance
(dB)
(maximum)
0.4
0.4
0.4
0.6
0.6
Phase
Balance
(Degrees)
(maximum)
5
5
5
5
5
VSWR In
(maximum)
1.2:1
1.3:1
1.2:1
1.3:1
1.3:1
VSWR Out
(maximum)
1.2:1
1.3:1
1.2:1
1.3:1
1.3:1
XMAPD10-1-4-2S*
XMAPD10-1-4-3S
XMAPD10-1-4-4S
XMAPD10-1-4-6S
XMAPD10-1-4-8S
2
3
4
6
8
49
Phone: 603-222-2256
fax: 603-222-2259
www.XMAcorp.com
sales@XMAcorp.com
2000-8000 MHz
Part Number
Channels
Isolation
(dB)
20
20
20
20
20
Insertion
Loss (dB)
(maximum)
0.6
0.7
0.7
0.8
0.8
Amplitude
Balance
(dB)
(maximum)
0.5
0.5
0.5
0.6
0.6
Phase
Balance
(Degrees)
(maximum)
5
5
5
5
5
VSWR In
(maximum)
1.2:1
1.3:1
1.2:1
1.3:1
1.3:1
VSWR Out
(maximum)
1.3:1
1.3:1
1.2:1
1.3:1
1.3:1
XMAPD10-2-8-2S
XMAPD10-2-8-3S
XMAPD10-2-8-4S
XMAPD10-2-8-6S
XMAPD10-2-8-8S
2
3
4
6
8
8000-18000 MHz
Part Number
Channels
Isolation
(dB)
17
17
17
17
17
Insertion
Loss (dB)
(maximum)
0.8
0.9
0.9
1.0
1.0
Amplitude
Balance
(dB)
(maximum)
0.5
0.5
0.5
0.6
0.6
Phase
Balance
(Degrees)
(maximum)
5
5
5
5
5
VSWR In
(
maximum)
1.3:1
1.4:1
1.3:1
1.4:1
1.3:1
VSWR Out
(maximum)
1.4:1
1.4:1
1.4:1
1.4:1
1.3:1
XMAPD10-8-18-2S
XMAPD10-8-18-3S
XMAPD10-8-18-4S
XMAPD10-8-18-4S
XMAPD10-8-18-4S
2
3
4
6
8
*Optional Connectors
S=SMA
N=Type
B=BNC
T=TNC
D=Din
DP=Drop In
Some connector configurations may not be available. Please contact XMA with specifications
Specifications subject to change without notice.
Phone: 603-222-2256
fax: 603-222-2259
www.XMAcorp.com
sales@XMAcorp.com
50
