2065-25-9 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 2065-25-9

2065-25-9: DescriptionRF BNC Connector, Male, Cable Mount, Crimp Terminal, Plug; CategoryThe connector The connector; File Size6MB，15 Pages; ManufacturerKings Electronics

Download Datasheet Parametric Compare View All

2065-25-9 Overview

RF BNC Connector, Male, Cable Mount, Crimp Terminal, Plug

2065-25-9 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
ECCN code	EAR99
Other features	APPLICABLE CABLES: BELDEN 1279P; BELDEN 1279R
Body/casing type	PLUG
Characteristic impedance	75 Ω
Connector type	RF BNC CONNECTOR
Contact to complete cooperation	GOLD
Contact completed and terminated	GOLD
Contact point gender	MALE
Coupling type	BAYONET
DIN compliance	NO
Filter function	NO
IEC compliance	NO
insulator material	POLYTETRAFLUORO ETHYLENE
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	2065
Installation method	STRAIGHT
Installation type	CABLE
Maximum operating frequency	5 GHz
Options	GENERAL PURPOSE
Panel mounting	NO
Termination type	CRIMP
voltage standing wave ratio	1.58
Base Number Matches	1

Preview

Download Datasheet

View All

Tri-Loc Series

Standard & Lo-Pro

Connectors

Jacks and Plugs

Your Solid, Point-To-Point Connection

Broadcast

Lo-Pro Tri-Loc®Connectors

Full Crimp Procedure

Ideally Suited for Outdoor

Use

Solid Reliability

Point-To-Point Solutions

Standard

Tri-Loc® Connectors

Two Crimp Procedure

Specifications

Material

Gaskets & Seals

Insulators

Spring Members

Balance of Metal

Components

Silicone Rubber

Teﬂon

Beryllium Copper

Contact

Resistance

Center Contacts <1.0 millohm

Intermediate Contact <0.2

millohm

Center Conductor/Intermediate

Contact: 1500 V rms

Intermediate Contact/Outer

Ground: 500 V rms

140 lbs min. for 1/2” dia. cable

100 lbs. min. for 3/8” diam. cable

Voltage

Breakdown

Brass

Finish

Center Contact

Balance of Metal

Components

Gold over Nickel

King’s tarnish resistant

ﬁnish TR-5

Mechanical

Cable Retention

Environmental

Altitude

Operating

Temperature

0 - 10,000 feet

Return Loss Graph

Lo-Pro

-20

C to +70

Electrical

Impedance

Operating

Frequency

75 ohms

DC To 2.5 GHz

2065-25-9 Related Products

	2065-25-9	2065-26-9
Description	RF BNC Connector, Male, Cable Mount, Crimp Terminal, Plug	RF BNC Connector, Male, Cable Mount, Crimp Terminal, Plug
Reach Compliance Code	unknow	unknow
ECCN code	EAR99	EAR99
Other features	APPLICABLE CABLES: BELDEN 1279P; BELDEN 1279R	APPLICABLE CABLES: RG 179; RG 187
Body/casing type	PLUG	PLUG
Characteristic impedance	75 Ω	75 Ω
Connector type	RF BNC CONNECTOR	RF BNC CONNECTOR
Contact to complete cooperation	GOLD	GOLD
Contact completed and terminated	GOLD	GOLD
Contact point gender	MALE	MALE
Coupling type	BAYONET	BAYONET
DIN compliance	NO	NO
Filter function	NO	NO
IEC compliance	NO	NO
insulator material	POLYTETRAFLUORO ETHYLENE	POLYTETRAFLUORO ETHYLENE
JESD-609 code	e4	e4
MIL compliance	NO	NO
Manufacturer's serial number	2065	2065
Installation method	STRAIGHT	STRAIGHT
Installation type	CABLE	CABLE
Maximum operating frequency	5 GHz	5 GHz
Options	GENERAL PURPOSE	GENERAL PURPOSE
Panel mounting	NO	NO
Termination type	CRIMP	CRIMP
voltage standing wave ratio	1.58	1.58
Base Number Matches	1	1
