NOTES: UNLESS OTHERWISE SPECIFIED
1. FOR USE WITH BELDEN 9529, 1505A & 1805F CABLES.
2. FOR CABLING INSTRUCTIONS SEE 3-661-1.
3. FOR CABLE TRIM M ING USE KTJ-57 & KTD-26.
4. FOR CRIM PING USE DIE KTH-2261.
5. INTERFACE PER KINGS ES-17, FIG. 6
6. M ATERIAL SPECIFICATIONS:
INSULATOR: TEFLON, ASTM -D-4894 OR ASTM D1710
GASKET: SILICONE RUBBER, A-A-59588
SPRING WASHER, OUTER CONTACT: BERYLLIUM COPPER PER ASTM B196
K-GRIP SLEEVE: COM M ERCIAL BRONZE, ASTM B135
ALL OTHER M ETAL PARTS: BRASS PER ASTM B16
7. FINISH SPECIFICATIONS:
CENTER CONTACT: GOLD PLATE PER M IL-G-45204
SRING WASHER: SILVER PLATE PER QQ-S-365 OR NICKEL PLATE PER QQ-N-290
ALL OTHER M ETAL PARTS:NICKEL PLATE PER QQ-N-290
8. ELECTRICAL SPECIFICATIONS:
IM PEDANCE: 75 OHM S
WORKING VOLTAGE: 500 VOLTS RM S
FREQUENCY RANGE: DC - 12 GHz
RETURN LOSS: -30dB M AX TO 3.0 GHz
-20dB M AX TO 6.0 GHz
9. COM PLIANT TO 3G/6G/12G SDI SM PTE REQUIREM ENTS.
1.21 30.73
REV
DESCRI PTI ON
BY
AP PD
D AT E
JI
04/1 0/15
YA
P
ER 0 5 7 7 9 8
.57 14.54
M ARK: KINGS 2065-2-9 (DATE CODE)
CATALOG P/N: 2065-2-9
PER ASME Y1 4. 5M-1 99 4
U NLESS OTHERWI SE SPECI FI ED:
DI MENSI ONS ARE I N I NC HES [ MM]
TOLER ANC ES:
DECI MAL: .XX [ X.X ] ± .01 [ 0.25]
. X XX [ X. XX] ± .0 0 4 [ 0 .1 0
. XXXX [ X.XXX ] ± .X XXX
ANG LES: ± 2°
SC ALE: 4:1
W i n c he s t e r E l e c t r o n i c s C o r p o r a t i o n
1 9 9 P a r k R o a d E x t S u ite 1 0 4
M id d le b u r y , C o n n e c tic u t 0 6 7 6 2
CUSTOMER
SALES DRAWING
D R AW N
TM L
APPRO VED
XXX
DM F 0 2 9 B
THI RD
ANG LE
D ATE APPR OVED
0 1/11/9 9
DC T
D ATE APPR OVED
X X/X X/X X XX X
D AT E
01/11/99
D AT E
XX/ XX/ XX
75 OHM BNC PLUG
FOR BELDEN 1505A
OR EQUIVALENT CABLE (RoHS)
A
SD2065-2-9
SH T
OF
R EV
1 1
P
