Data Sheet No. 2C5004
Chip Type 2C5004
Geometry 9202
Polarity NPN
Generic Packaged Parts:
2N5002, 2N5004
Chip type
2C5004
by Semicoa Semi-
conductors provides performance
similar to these devices.
Part Numbers:
2N5002, 2N5004
Product Summary:
APPLICATIONS:
Designed for medium
power amplifier and switching and wide
band amplifier applications.
Features:
•
Medium power ratings
Mechanical Specifications
Metallization
Bonding Pad Size
Die Thickness
Chip Area
Top Surface
Top
Backside
Emitter
Base
Al - 37.5 kÅ min.
Au - 6.5 kÅ nom.
12 mils x 40 mils
12 mils x 30 mils
8 mils nominal
100 mils x 100 mils
Silox Passivated
Electrical Characteristics
T
A
= 25
o
C
Parameter
BV
CBO
I
CEO
I
CES
I
EBO
Test conditions
I
C
= 10 mA, I
E
= 0
V
CE
= 40 Vc, I
B
= 0
V
CE
= 100 Vc, V
BE
= 0
V
EB
= 5.5 V
C
, I
C
= 0
Min
80
---
---
---
Max
---
50
1.0
1.0
Unit
V dc
µA
mA
mA
h
FE
I
C
= 50 mA dc, V
CE
= 5.0 V
50
---
---
Due to limitations of probe testing, only dc parameters are tested. This must be done with pulse width less
than 300 µs, duty cycle less than 2%.
