SMD
Side View LEDs
3006UM2C/L7280J5M6U28/TR8-T/ES
Features
․Side
view white LED
․White
SMT package
․Lead
frame package with individual 2 pins
․Wide
viewing angle
․Soldering
methods: IR reflow soldering
․Pb-free
․The
product itself will remain within RoHS compliant version.
․Compliance
with EU REACH.
․Compliance
Halogen Free .(Br <900 ppm ,Cl <900 ppm , Br+Cl < 1500 ppm).
Descriptions
Due to the package design, 3006 has wide viewing angle, low power consumption and white LEDs are devices that are
materialized by combing blue chips and special phosphor. This feature makes the LED ideal for light guide application.
Applications
․Mobile
Phones
․Indicators
1
Copyright © 2010, Everlight All Rights Reserved. Release Date : 20.Apr.2015. Issue No: V1
Issue No: DSE-0013082
www.everlight.com
DATASHEET
SMD
Side View LEDs
3006UM2C/L7280J5M6U28/TR8-T/ES
Device Selection Guide
Chip Materials
InGaN
Emitted Color
Pure White
Resin Color
Water Clear
Absolute Maximum Ratings (Ta=25℃)
Materials
everse Voltage
Forward Current
Peak Forward Current (Duty 1/10 @10ms)
Power Dissipation
Operating Temperature
Storage Temperature
Soldering Temperature
Electrostatic Discharge(HBM)*1
Materials
V
R
I
F
I
FP
P
d
T
opr
T
stg
T
sol
ESD
Materials
5
30
60
110
-40 ~ +85
-40 ~ +90
Material
s
V
mA
mA
mW
℃
℃
Reflow Soldering : 260
℃
for 10 sec.
Hand Soldering : 350
℃
for 3 sec.
2KV, Test/Result: 0/50.
Test Times: 3Time.
Notes: *1The products are sensitive to static electricity and must be carefully taken when handling products.
Electro-Optical
OOaracteristics
(Ta=25
℃
)
Parameter
Luminous Flux
Viewing Angle
Forward Voltage
Reverse Current
Notes:
1. Tolerance of Luminous Flux: ± 7%
2. Tolerance of Forward Voltage: ± 0.05V
Symbol
Φ
2θ1/2
V
F
I
R
Min.
7.25
-----
2.70
-----
Typ.
-----
115
-----
-----
Max.
8.25
-----
3.40
50
Unit
lm
deg
V
μA
Condition
I
F
=20mA
I
F
=20mA
I
F
=20mA
V
R
=5V
2
Copyright © 2010, Everlight All Rights Reserved. Release Date : 20.Apr.2015. Issue No: V1
Issue No: DSE-0013082
www.everlight.com
DATASHEET
SMD
Side View LEDs
3006UM2C/L7280J5M6U28/TR8-T/ES
Bin Range of Luminous Flux
Bin Code
L72
L75
L77
L80
Lm(Min.)
7.25
7.50
7.75
8.00
Lm(Max.)
7.50
7.75
8.00
8.25
lm
I
F
=20mA
Unit
Condition
Mcd(Min.)
2595
2685
2775
2865
Mcd(Max.)
2685
2775
2865
2955
Note: Tolerance of Luminous Flux: ± 7%
Bin Range of Forward Voltage
Bin Code
Min.
Max.
Unit
Condition
U2
U3
U4
U5
U6
U7
U8
2.70
2.80
2.90
3.00
3.10
3.20
3.30
2.80
2.90
3.00
3.10
3.20
3.30
3.40
V
IF=20mA
Note: Tolerance of Forward Voltage: ± 0.05V
3
Copyright © 2010, Everlight All Rights Reserved. Release Date : 20.Apr.2015. Issue No: V1
Issue No: DSE-0013082
www.everlight.com
DATASHEET
SMD
Side View LEDs
3006UM2C/L7280J5M6U28/TR8-T/ES
Bin Range of
OOromaticity Ooordinate
Bin Code
CIE_x
0.2800
J5
0.2800
0.2850
0.2850
0.2850
K5
0.2850
0.2900
0.2900
0.2900
L5
0.2900
0.2950
0.2950
0.2950
M5
0.2950
0.3000
0.3000
Note: Tolerance of Chromaticity Coordinates: ±0.01
CIE_y
0.2566
0.2666
0.2758
0.2658
0.2658
0.2758
0.2850
0.2750
0.2750
0.2850
0.2942
0.2842
0.2842
0.2942
0.3034
0.2934
Bin Code
CIE_x
0.2800
CIE_y
0.2466
0.2566
0.2658
0.2558
0.2558
0.2658
0.2750
0.2650
0.2650
0.2750
0.2842
0.2742
0.2742
0.2842
0.2934
0.2834
J6
0.2800
0.2850
0.2850
0.2850
K6
0.2850
0.2900
0.2900
0.2900
0.2900
0.2950
0.2950
0.2950
0.2950
0.3000
0.3000
L6
M6
4
Copyright © 2010, Everlight All Rights Reserved. Release Date : 20.Apr.2015. Issue No: V1
Issue No: DSE-0013082
www.everlight.com
DATASHEET
SMD
Side View LEDs
3006UM2C/L7280J5M6U28/TR8-T/ES
TOe
O.I.E.
1931
OOromaticity
Diagram
