RL64-181K: DescriptionGeneral Purpose Inductor, 180uH, 10%, 1 Element; CategoryPassive components inductor; File Size15KB，1 Pages; ManufacturerInductor Supply Inc

Download Datasheet Parametric View All

RL64-181K Overview

General Purpose Inductor, 180uH, 10%, 1 Element

RL64-181K Parametric

Parameter Name	Attribute value
Maker	Inductor Supply Inc
Reach Compliance Code	unknown
ECCN code	EAR99
DC Resistance	0.74 Ω
Nominal inductance(L)	180 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Manufacturer's serial number	RL64
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Maximum rated current	0.44 A
self resonant frequency	5.7 MHz
Shape/Size Description	CYLINDRICAL PACKAGE
shield	NO
surface mount	NO
Terminal location	RADIAL
Terminal shape	PRINTED WIRING PIN
Test frequency	0.001 MHz
Tolerance	10%

Preview

Download Datasheet

View All

RL64

Radial

Leaded R.F .

0.26

Max.

0.24

0.20

0.158

0.028

MARKING Inductance value

PACKAGING Bulk or Tape and Reel.

INDUCTANCES 22µH to 1,000µH

OPERATING TEMPERATURE RANGE -55°C to +125°C

CURRENT RATING Based on maximum of 10% drop from

initial value.

TEST

FREQUENCY

(Mhz)

2.52

(Khz)

RL64-101K

RL64-121K

RL64-151K

RL64-181K

RL64-221K

RL64-271K

RL64-331K

RL64-391K

RL64-471K

RL64-561K

RL64-681K

RL64-821K

RL64-102K

100

120

150

180

220

270

330

390

470

560

680

820

1000

1

Notes:

(1) Inductance Range measur ed on HP4342A Q-meter.

(2) Inductance Range: 100µH - 1.000µH measured on GenRad 1658 Dig i-

Br idge.

(3) Ra ted DC tested at 1kHz, I, dc is the minim um current at which the

inductance will be decreased by 10% from its initial (zero-DC) value

beacause of saturation.

(4) DCR measured with GenRad 1658 Digi-Bridge.

PART

NUMBER

RL64-220K

RL64-270K

RL64-330K

RL64-390K

RL64-470K

RL64-560K

RL64-680K

RL64-820K

INDUCT ANCE

(µhy)

22

27

33

39

47

56

68

82

SELF RESONANT

FREQUENCY

MINIMUM (Mhz)

18

16

15

13

12

11

10

9.3

DC RESIST ANCE

OHMS

MAXIMUM (Ω )

.11

.14

.17

.19

.23

.26

.28

.39

RATED DC

CURRENT MAX

(mA)

1270

1140

1030

950

870

800

720

660

8.4

7.0

6.2

5.7

5.4

5.1

4.3

4.1

3.8

3.0

2.8

2.6

2.5

.43

.54

.64

.74

.96

1.12

1.48

1.66

1.91

2.31

2.67

3.10

4.45

590

540

480

440

400

360

330

300

270

250

230

210

190
