3-1622825-1

Description
RESISTOR, CURRENT SENSE, METAL GLAZE/THICK FILM, 0.25W, 5%, 200ppm, 0.68ohm, SURFACE MOUNT, 1206, CHIP, ROHS COMPLIANT
CategoryPassive components    The resistor
File Size100KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

3-1622825-1 Online Shopping

Suppliers Part Number Price MOQ In stock
3-1622825-1 - - View Buy Now

3-1622825-1 Overview

RESISTOR, CURRENT SENSE, METAL GLAZE/THICK FILM, 0.25W, 5%, 200ppm, 0.68ohm, SURFACE MOUNT, 1206, CHIP, ROHS COMPLIANT

3-1622825-1 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
package instruction, 1206
Reach Compliance Codecompli
Installation featuresSURFACE MOUNT
Number of terminals2
Package shapeRECTANGULAR PACKAGE
method of packingTR
Rated power dissipation(P)0.25 W
resistance0.68 Ω
Resistor typeFIXED RESISTOR
size code1206
surface mountYES
technologyMETAL GLAZE/THICK FILM
Temperature Coefficient200 ppm/°C
Terminal shapeWRAPAROUND
Tolerance5%
Base Number Matches1
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Resistors
>
Product Feature Selector
> Product Details
RL73K2BR68JTD Product Details
Live Product Chat
Fixed Resistors
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
RL73K2BR68JTD
(3-1622825-1)
T E I nternal N umber: 3 - 1 6 2 2 8 2 5 - 1
Product Highlights:
l
Resistor Type = C urrent Sensing Resistor
l
Resistance Selection = <1K ?
l
Resistance = .68 ?
l
Power Rating = .25 W
l
Tolerance = 5 %
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
Type RL73 Series SMD Low Ohmic - C urrent Sense Resistors
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Resistor Type = C urrent Sensing Resistor
l
Resistance (?)
= .68
l
Element
= Thick Film
l
Termination Type = Solder
Electrical Characteristics:
l
Resistance Selection (?)
= <1K
l
Power Rating (W)
= 0.25
l
Tolerance (%)
= 5
l
Package Type
= Taped and Reeled
Body Related Features:
l
Series
= RL73
l
Mount Style
= Surface Mount
l
Packaging Style
= 1206
l
Package, C omponent Size
= 3.1 x 1.55
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Reflow solder capable to 245?C ,
Reflow solder capable to 260?C
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Conditions for Usage:
l
Temperature C oefficient (ppm/?C )
= ?200
Operation/Application:
l
Application
= C urrent Sensing
Other:
l
Brand = C GS
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved
