PMSS–05–18–SP–03.50–S
F-209
IPBD–04–D
PMSD–10–18–SP−03.50−D−MUS
POWER MATE CABLE
Mates with:
IPBT
™
PMSD, PMSS,
IPBD SERIES
ASSEMBLED
LENGTH
END
OPTION
LATCH
OPTION
TYPE
PINS
PER ROW
WIRE
GAUGE
LEAD
STYLE
SPECIFICATIONS
For complete specifications
see www.samtec.com?PMSD,
www.samtec.com?PMSS or
www.samtec.com?IPBD
Insulator Material:
Valox 457
Contact Material:
−SP= Phosphor Bronze
−HP= High Copper Alloy
Plating:
Sn over 50µ" (1,27µm) Ni
Operating Temp Range:
-40°C to +105°C
Voltage Rating:
22 & 24 AWG = 300 VAC
16, 18 & 20 AWG = 600 VAC
Wire:
16 to 24 AWG
RoHS Compliant:
Yes
CURRENT RATING
AMBIENT
TEMP
20°C
40°C
60°C
75°C
PMSS/IPBT
8.9A
8.2A
6.8A
5.5A
PMSD
= Double Row
–02, –03,
–04, –05,
–10, –15
–16
–18
–206
(20 AWG/
600 volts)
–SP
= Standard
Power
–“XX.XX”
= Wire
Length
in Inches
(88,90mm)
03.50" min.
–S
= Single End
–HP
= High
Power
–D–MUX
(4,19) .165
–D
= Double End
(Latch required)
PMSS
= Single Row
(–02, –03,
–04, –05)
–22
–24
No. of Positions x (4,19) .165
+ (1,02) .040
10
02 01
Ended, Metal Latches
–M
= Single only (Leave blank for plastic)
PMSD
Double Ended (–D) Crossed requires PMSD
(12,14)
.478
(4,19)
.165
20
11
PMSD
No. of Positions x (4,19) .165
+ (1,02) .040
02 01
Assembled
Length
± (3,18)
.125
10
6 POSITIONS (SP) IN LINE POWERED
(5,41)
.213
(7,95) .313
APPLICATION
SPECIFIC OPTION
• Color coded cables.
• Other sizes/pin counts.
• 20 AWG/300 Volts
Call Samtec.
PMSS
–D–LUS
–LUS
= Plastic Latch up, straight
–LDS
= Plastic Latch down, straight
–LUX
= Plastic Latch up, crossed
–LDX
= Plastic Latch down, crossed
–MUS
= Metal Latch up, straight
–MDS
= Metal Latch down, straight
–MUX
= Metal Latch up, crossed
–MDX
= Metal Latch down, crossed
TYPE
POSITIONS
PER ROW
ROW
OPTION
LATCH
OPTION
TYPE
WIRE
GAUGE
01
T
LEAD
STYLE
IPBD
= Body,
Loose
–02, –03,
–04, –05,
–10, –15
(–D only)
–S
= Single
Row
–M
= Metal
Latch
(Leave
blank for
plastic
latch)
(–D only)
–SP
CC69L
= Contact,
Loose
–2024
= 20 to 24 AWG
–T
= Tin
= Standard
Power
–D
= Double
Row
–02, –03,
–04, –05
(–S only)
CC69R
= Contact,
Full Reel
(4,000 Parts
per Reel)
–1620
= 16 to 20 AWG
–HP
= High
Power
(13,21)
.520
HAND TOOLS
(19,56)
.770
(12,32)
.485
(19,23)
.757
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
–S
–D
–M
(–D ONLY)
16 to 20 AWG:
CAT-HT-169-1620-11
20 to 24 AWG:
CAT-HT-169-2024-11
(1,57)
.062
DIA
(3,81)
.150
(1,91)
.075
(5,40)
.2125
WWW.SAMTEC.COM
