V7-T1-84
Pushbuttons and Indicating Lights
22.5 mm Modular Pushbuttons—M22
Catalog Number Selection
Catalog Number Selection is for illustrative purposes only and not to be used to create new catalog numbers.
Illuminated Selector Switches
M22 – WLK – R – K10 – R
Bezel
M22
= Silver
M22S
= Black
M22M
= Metal
Handle Type
WLK
= Illuminated knob type
momentary, two-position
WLKV
= Illuminated Knob type
momentary, V-position
WLK3
= Illuminated knob type
momentary, three-position
Handle Color
W
= White
R
= Red
G
= Green
Y
= Yellow
B
= Blue
Contact Blocks
1NO
K30
= 3NO
1NC
K03
= 3NC
2NO
K21
= 2NO-1NC
2NC
K12
= 1NO-2NC
1NO-1NC
Light Units
12–30 Vac/Vdc
W
= White
R
= Red
G
= Green
B
= Blue
85–264 Vac
230W
= White
230R
= Red
230G
= Green
230B
= Blue
K10
=
K01
=
K20
=
K02
=
K11
=
Volume 7—Logic Control, Operator Interface and Connectivity Solutions
CA08100008E—March 2014 www.eaton.com
Pushbuttons and Indicating Lights
22.5 mm Modular Pushbuttons—M22
1.5
1
1
1
Product Selection
Illuminated Selector Switches
Components
M22-WLK-W
Operators Only, Knob Type
1
Type
Two-position
Switching Position
Momentary
2
40°
Button Color
White
Red
Green
Yellow
Blue
Maintained
40°
White
Red
Green
Yellow
Blue
Maintained V
60°
White
Red
Green
Yellow
Blue
Silver Bezel
Catalog Number
M22-WLK-W
M22-WLK-R
M22-WLK-G
M22-WLK-Y
M22-WLK-B
M22-WRLK-W
M22-WRLK-R
M22-WRLK-G
M22-WRLK-Y
M22-WRLK-B
M22-WLKV-W
M22-WLKV-R
M22-WLKV-G
M22-WLKV-Y
M22-WLKV-B
Black Bezel
Catalog Number
M22S-WLK-W
M22S-WLK-R
M22S-WLK-G
M22S-WLK-Y
M22S-WLK-B
M22S-WRLK-W
M22S-WRLK-R
M22S-WRLK-G
M22S-WRLK-Y
M22S-WRLK-B
M22S-WLKV-W
M22S-WLKV-R
M22S-WLKV-G
M22S-WLKV-Y
M22S-WLKV-B
Metal Bezel
Catalog Number
M22M-WLK-W
M22M-WLK-R
M22M-WLK-G
M22M-WLK-Y
M22M-WLK-B
M22M-WRLK-W
M22M-WRLK-R
M22M-WRLK-G
M22M-WRLK-Y
M22M-WRLK-B
M22M-WLKV-W
M22M-WLKV-R
M22M-WLKV-G
M22M-WLKV-Y
M22M-WLKV-B
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Notes
1
Includes contact block mounting adapter.
2
Momentary selector switches can be converted in the field to maintained operation with the removal of a color coded
adapter. See
Page V7-T1-118.
Volume 7—Logic Control, Operator Interface and Connectivity Solutions
CA08100008E—March 2014 www.eaton.com
V7-T1-85
1.5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
V7-T1-86
M22-WLK3-W
Pushbuttons and Indicating Lights
22.5 mm Modular Pushbuttons—M22
Illuminated Selector Switches
Components
Operators Only, Knob Type
1
Type
Three-position
Switching Position
Momentary
2
40°
40°
Button Color
White
Red
Green
Yellow
Blue
Maintained
60°
60°
White
Red
Green
Yellow
Blue
Maintained, return from right
40°
40° 60°
60°
White
Red
Green
Yellow
Blue
Maintained, return from left
40°
40° 60°
60°
White
Red
Green
Yellow
Blue
Silver Bezel
Catalog Number
M22-WLK3-W
M22-WLK3-R
M22-WLK3-G
M22-WLK3-Y
M22-WLK3-B
M22-WRLK3-W
M22-WRLK3-R
M22-WRLK3-G
M22-WRLK3-Y
M22-WRLK3-B
M22-WRLK3-1-W
M22-WRLK3-1-R
M22-WRLK3-1-G
M22-WRLK3-1-Y
M22-WRLK3-1-B
M22-WRLK3-2-W
M22-WRLK3-2-R
M22-WRLK3-2-G
M22-WRLK3-2-Y
M22-WRLK3-2-B
Black Bezel
Catalog Number
M22S-WLK3-W
M22S-WLK3-R
M22S-WLK3-G
M22S-WLK3-Y
M22S-WLK3-B
M22S-WRLK3-W
M22S-WRLK3-R
M22S-WRLK3-G
M22S-WRLK3-Y
M22S-WRLK3-B
M22S-WRLK3-1-W
M22S-WRLK3-1-R
M22S-WRLK3-1-G
M22S-WRLK3-1-Y
M22S-WRLK3-1-B
M22S-WRLK3-2-W
M22S-WRLK3-2-R
M22S-WRLK3-2-G
M22S-WRLK3-2-Y
M22S-WRLK3-2-B
Metal Bezel
Catalog Number
M22M-WLK3-W
M22M-WLK3-R
M22M-WLK3-G
M22M-WLK3-Y
M22M-WLK3-B
M22M-WRLK3-W
M22M-WRLK3-R
M22M-WRLK3-G
M22M-WRLK3-Y
M22M-WRLK3-B
M22M-WRLK3-1-W
M22M-WRLK3-1-R
M22M-WRLK3-1-G
M22M-WRLK3-1-Y
M22M-WRLK3-1-B
M22M-WRLK3-2-W
M22M-WRLK3-2-R
M22M-WRLK3-2-G
M22M-WRLK3-2-Y
M22M-WRLK3-2-B
Notes
1
Includes contact block mounting adapter.
2
Momentary selector switches can be converted in the field to maintained operation with the removal of a color coded
adapter. See
Page V7-T1-118.
Volume 7—Logic Control, Operator Interface and Connectivity Solutions
CA08100008E—March 2014 www.eaton.com
Pushbuttons and Indicating Lights
22.5 mm Modular Pushbuttons—M22
1.5
1
1
1
1
1
1
1
1
1
Catalog Number
M22-XW
Illuminated Selector Switches
ma
x
thic . 5mm
kne
ss
Note: Included
with operator.
M22-LED-W
Light Units
1 5
Terminal
Type
Screw
LED
Color
White
Red
Green
Blue
White
Red
Green
Blue
Light Unit
Voltage
12–30
Vac/Vdc
Catalog Number
M22-LED-W
M22-LED-R
M22-LED-G
M22-LED-B
M22-LED230-W
M22-LED230-R
M22-LED230-G
M22-LED230-B
M22-XW
Accessories
Description
Plunger bridge
2
1
1
1
Screw
85–264
Vac
M22-XWS
Key cover
M22-XWS
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
M22-XC-R
M22-K10
Key withdraw adapter
4
M22-XC-R
Contact Blocks
Terminal
Type
Screw
1
Contact
Configuration
NO
NO, early-make
NC
NC, late-break
NO
NC
NC, late-break
2NO
2NC
NO-NC
3
Catalog Number
M22-K10
M22-K10P
M22-K01
M22-K01D
M22-CK10
M22-CK01
M22-CK01D
M22-CK20
M22-CK02
M22-CK11
M22-XC-Y
Coding adapter
M22-XC-Y
Spring-cage
M22-XGWK
Guard ring
M22-XGWK
Notes
1
For complete listing of available light units and contact blocks, see Accessories,
Pages V7-T1-111
to
V7-T1-116.
2
Plunger needed to actuate center-mounted contact blocks. Used for non-illuminated
three-position selector switches only.
3
All NC contact blocks are positively driven contact.
4
Enables a keyed selector switch to be set to user-selected key withdraw position.
5
Select the same color LED element as lens color; for yellow lens, choose a white LED.
Volume 7—Logic Control, Operator Interface and Connectivity Solutions
CA08100008E—March 2014 www.eaton.com
V7-T1-87
