DATA SHEET
PHOTOCOUPLER
PS2511-1,-2,-4, PS2511L-1,-2,-4
HIGH ISOLATION VOLTAGE
STANDARD MULTI PHOTOCOUPLER SERIES
SINGLE TRANSISTOR TYPE
DESCRIPTION
and an NPN silicon phototransistor.
(Gull-wing) for surface mount.
−NEPOC
TM
Series−
The PS2511-1, -2, -4 and PS2511L-1, -2, -4 are optically coupled isolators containing a GaAs light emitting diode
The PS2511-1, -2, -4 are in a plastic DIP (Dual In-line Package) and the PS2511L-1, -2, -4 are lead bending type
FEATURES
• High isolation voltage (BV = 5 000 Vr.m.s.)
• High current transfer ratio (CTR = 200 % TYP.)
• High-speed switching (t
r
= 3
µ
s TYP., t
f
= 5
µ
s TYP.)
• UL approved : File No. E72422 (S)
• Taping Product number : PS2511L-1-E3, E4, F3, F4, PS2511L-2-E3, E4
APPLICATIONS
• Power supply
• Telephone/FAX.
• FA/OA equipment
• Programmable logic controller
D
is
Document No. P12975EJ1V0DS00 (1st edition)
Date Published October 1998 NS CP(K)
