PNP SILICON SWITCHING TRANSISTOR
Qualified per MIL-PRF-19500/512
DEVICES
LEVELS
2N4029
2N4033
2N4033UA
2N4033UB
JAN
JANTX
JANTXV
JANS
ABSOLUTE MAXIMUM RATINGS
(T
C
= +25°C unless otherwise noted)
Parameters / Test Conditions
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage
Collector Current
Total Power Dissipation @ T
A
=
+25°C
2N4029
1
2N4033
2
2N4033UA, UB
3
2N4029
2N4033
Symbol
V
CEO
V
CBO
V
EBO
I
C
P
T
T
j
, T
stg
R
θJC
Value
80
80
5.0
1.0
0.5
0.8
0.5
-65 to +200
80
40
Unit
Vdc
Vdc
Vdc
Adc
W
°C
°C/W
TO-18 (TO-206AA)
2N4029
Operating & Storage Junction Temperature Range
Thermal Resistance, Junction-to-Case
Note:
1.
2.
3.
Derate linearly 2.86mW/°C for T
A
> +25°C
Derate linearly 4.56mW/°C for T
A
> +25°C
For UB package and use R
θJC
or see thermal curves in /512
TO-39 (TO-205AD)
2N4033
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, unless otherwise noted)
Parameters / Test Conditions
OFF CHARACTERTICS
Symbol
Min.
Max.
Unit
Collector-Base Cutoff Current
V
CB
= 80Vdc
V
CB
= 60Vdc
V
CB
= 60Vdc, T
A
= +150°C
Emitter-Base Cutoff Current
V
EB
= 5.0Vdc
V
EB
= 3.0Vdc
Collector-Emitter Cutoff Current
V
BE
= 2.0Vdc, V
CE
= 60Vdc
I
CBO
10
10
25
10
25
25
μAdc
ηAdc
μAdc
μAdc
ηAdc
ηAdc
UA Package
I
EBO
I
CEX
UB Package
Page 1 of 6
T4-LDS-0157 Rev. 2 (101305)
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland.
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
ELECTRICAL CHARACTERISTICS
(T
A
= +25°C, unless otherwise noted)
Parameters / Test Conditions
ON CHARACTERISTICS
(3)
Forward-Current Transfer Ratio
I
C
= 100μAdc, V
CE
= 5.0Vdc
I
C
= 100mAdc, V
CE
= 5.0Vdc
I
C
= 500mAdc, V
CE
= 5.0Vdc
I
C
= 1.0Adc, V
CE
= 5.0Vdc
I
C
= 500mAdc, V
CE
= 5.0Vdc, T
A
= -55°C
Collector-Emitter Saturation Voltage
I
C
= 150mAdc, I
B
= 15mAdc
I
C
= 500mAdc, I
B
= 50mAdc
I
C
= 1.0Adc, I
B
= 100mAdc
Base-Emitter Voltage
I
C
= 150mAdc, I
B
= 15mAdc
I
C
= 500mAdc, I
B
= 50mAdc
DYNAMIC CHARACTERISTICS
Parameters / Test Conditions
Magnitude of Common Emitter Small–Signal Short-Circuit Forward
Current Transfer Ratio
I
C
= 50mAdc, V
CE
= 10Vdc, f = 100MHz
Output Capacitance
V
CB
= 10Vdc, I
E
= 0, 100kHz
≤
f
≤
1.0MHz
Input Capacitance
V
EB
= 0.5Vdc, I
C
= 0, 100kHz
≤
f
≤
1.0MHz
SWITCHING CHARACTERISTICS
Parameters / Test Conditions
On-Time
V
CC
= 31.9Vdc; I
C
= 500mAdc; I
B1
= 50mAdc
Rise Time
V
CC
= 31.9Vdc; I
C
= 500mAdc; I
B1
= 50mAdc
Storage Time
V
CC
= 31.9V, I
C
= 500madc, I
B1
= 50mAdc
Fall Time
V
CC
= 31.9V, I
C
= 500madc, I
B1
= 50mAdc
(4) Pulse Test: Pulse Width = 300μs, Duty Cycle
≤
2.0%.
Symbol
Min.
Max.
Unit
h
FE
50
100
70
25
30
300
V
CE(sat)
0.15
0.50
1.0
0.9
1.2
Vdc
V
BE(sat)
Vdc
Symbol
|h
fe
|
Min.
Max.
Unit
1.5
6.0
20
80
pF
pF
C
obo
C
ibo
Symbol
t
Min.
Max.
15
25
175
35
Unit
ηs
ηs
ηs
ηs
d
r
t
t
s
f
t
T4-LDS-0157 Rev. 2 (101305)
Page 2 of 6
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland.
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
PACKAGE DIMENSIONS
Symbol
CD
CH
HD
LC
LD
LL
LU
L
1
L
2
Q
TL
TW
r
P
α
Dimensions
Inches
Millimeters
Min Max Min
Max
.178 .195 4.52
4.95
.170 .210 4.32
5.34
.209 .230 5.31
5.84
.100 TP
2.54 TP
.016 .021 0.41
0.53
.500 .750 12.70 19.05
.016 .019 0.41
0.48
.050
1.27
.250
6.35
.040
1.02
.028 .048 0.71
1.22
.036 .046 0.91
1.17
.010
0.25
.100
2.54
45° TP
Notes
6
7, 8
7, 8, 12
7, 8
7, 8
7, 8
5
3, 4
3
10
6
NOTES:
1 Dimension are in inches.
2 Millimeters equivalents are given for general information only.
3 Beyond r (radius) maximum, TW shall be held for a minimum length of .011 (0.28 mm).
4 Dimension TL measured from maximum HD.
5 Body contour optional within zone defined by HD, CD, and Q.
6 Leads at gauge plane .054 +.001 -.000 inch (1.37 +0.03 -0.00 mm) below seating plane shall be within .007 inch (0.18mm)
radius of true position (TP) at maximum material condition (MMC) relative to tab at MMC. The device may be measured by
direct methods.
7 Dimension LU applies between L
1
and L
2
. Dimension LD applies between L
2
and minimum. Diameter is uncontrolled in L
1
and beyond LL minimum.
8 All three leads.
9 The collector shall be internally connected to the case.
10 Dimension r (radius) applies to both inside corners of tab.
11 In accordance with ASME Y14.5M, diameters are equivalent to
φx
symbology.
12 For “L” suffix devices, dimension LL is 1.50 (38.10mm) minimum, 1.75 (44.45mm) maximum.
FIGURE 1. Physical dimensions for 2N4029 (TO-18).
T4-LDS-0157 Rev. 2 (101305)
Page 3 of 6
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland.
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
Symbol
CD
CH
HD
LC
LD
LL
LU
L
1
L
2
Q
TL
TW
r
P
α
Dimensions
Inches
Millimeters
Min Max Min
Max
.305 .335 7.75
8.51
.240 .260 6.10
6.60
.335 .370 8.51
9.40
.200 TP
5.08 TP
.016 .021 0.41
0.53
.500 .750 12.70 19.05
.016 .019 0.41
0.48
.050
1.27
.250
6.35
.050
1.27
.029 .045 0.74
1.14
.028 .034 0.71
0.86
.010
0.25
.100
2.54
45° TP
Notes
6
7, 8
7, 8, 12
7, 8
7, 8
7, 8
5
3, 4
3
10
6
NOTES:
1 Dimension are in inches.
2 Millimeters equivalents are given for general information only.
3 Beyond r (radius) maximum, TW shall be held for a minimum length of .011 (0.28 mm).
4 Dimension TL measured from maximum HD.
5 Body contour optional within zone defined by HD, CD, and Q.
6 Leads at gauge plane .054 +.001 -.000 inch (1.37 +0.03 -0.00 mm) below seating plane shall be within .007 inch (0.18mm)
radius of true position (TP) at maximum material condition (MMC) relative to tab at MMC. The device may be measured by
direct methods.
7 Dimension LU applies between L
1
and L
2
. Dimension LD applies between L
2
and minimum. Diameter is uncontrolled in L
1
and beyond LL minimum.
8 All three leads.
9 The collector shall be internally connected to the case.
10 Dimension r (radius) applies to both inside corners of tab.
11 In accordance with ASME Y14.5M, diameters are equivalent to
φx
symbology.
12 For “L” suffix devices, dimension LL is 1.50 (38.10mm) minimum, 1.75 (44.45mm) maximum.
FIGURE 2. Physical dimensions for 2N4033 (TO-39).
T4-LDS-0157 Rev. 2 (101305)
Page 4 of 6
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http://www.microsemi.com
Gort Road Business Park, Ennis, Co. Clare, Ireland.
Tel: +353 (0) 65 6840044 Fax: +353 (0) 65 6822298
Ltr.
A
A
1
B
1
B
2
B
3
D
D
1
Dimensions
Inches
Millimeters
Min Max Min Max
.061 .075 1.55 1.91
.029 .041 0.74 1.04
.022 .028 0.56 0.71
.075 REF
1.91 REF
.006 .022 0.15 0.56
.145 .155 3.68 3.93
.045 .055 1.14 1.39
Note
3
Ltr.
D
2
D
3
E
E
3
L
1
L
2
L
3
5
Dimensions
Inches
Millimeters
Min
Max
Min
Max
.0375 BSC
0.952 BSC
.155
3.94
.215
.225
5.46
5.72
.225
5.72
.032
.048
0.81
1.22
.072
.088
1.83
2.24
.003
.007
0.08
0.18
Note
5
NOTES:
1 Dimensions are in inches.
2 Millimeters equivalents are given for general information only.
3 Dimension “A” controls the overall package thickness. When a window lid is used, dimension “A” must increase by a
minimum of .010 inch (0.254 mm) and a maximum of .040 inch (1.020 mm).
4 The corner shape (square, notch, radius, etc) may vary at the manufacturer’s option, from that shown on the drawing.
5 Dimensions “B3” minimum and “L3” minimum and the appropriately castellation length define an unobstructed three-
dimensional space traversing all of the ceramic layers in which a castellation was designed. (Castellations are required on
bottom two layers, optional on top ceramic layer.) Dimension “B3” maximum and “L3” maximum define the maximum width
and depth of the castellation at any point on its surface. Measurement of these dimensions may be made prior to solder dipping.
6 In accordance with ASME Y14.5M, diameters are equivalent to
φx
symbology.
FIGURE 3. Physical dimensions, surface mount (UA version).
T4-LDS-0157 Rev. 2 (101305)
Page 5 of 6
