LM2661MM datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> LM2661MM

LM2661MM: DescriptionSWITCHED CAPACITOR CONVERTER, 80kHz SWITCHING FREQ-MAX, PDSO8, MINI, SO-8; CategoryPower/power management The power supply circuit; File Size1002KB，14 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

LM2661MM Overview

SWITCHED CAPACITOR CONVERTER, 80kHz SWITCHING FREQ-MAX, PDSO8, MINI, SO-8

LM2661MM Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	incompatible
Parts packaging code	SOIC
package instruction	MINI, SO-8
Contacts	8
Reach Compliance Code	unknow
Analog Integrated Circuits - Other Types	SWITCHED CAPACITOR CONVERTER
Maximum input voltage	5.5 V
Minimum input voltage	1.5 V
Nominal input voltage	5 V
JESD-30 code	S-PDSO-G8
JESD-609 code	e0
length	3 mm
Humidity sensitivity level	1
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Package shape	SQUARE
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
Maximum seat height	1.09 mm
surface mount	YES
Switch configuration	DOUBLER INVERTER
Maximum switching frequency	80 kHz
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
width	3 mm
Base Number Matches	1
