UC2544J

Description
1-CHANNEL POWER SUPPLY SUPPORT CKT, CDIP18, CERAMIC, DIP-18
CategoryPower/power management    The power supply circuit
File Size2MB,21 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Download Datasheet Parametric Compare View All

UC2544J Overview

1-CHANNEL POWER SUPPLY SUPPORT CKT, CDIP18, CERAMIC, DIP-18

UC2544J Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerRochester Electronics
Parts packaging codeDIP
package instructionCERAMIC, DIP-18
Contacts18
Reach Compliance Codeunknown
Adjustable thresholdNO
Analog Integrated Circuits - Other TypesPOWER SUPPLY SUPPORT CIRCUIT
JESD-30 codeR-GDIP-T18
JESD-609 codee0
length19.305 mm
Humidity sensitivity levelNOT SPECIFIED
Number of channels1
Number of functions1
Number of terminals18
Maximum operating temperature85 °C
Minimum operating temperature-25 °C
Package body materialCERAMIC, GLASS-SEALED
encapsulated codeDIP
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Maximum seat height5.08 mm
Maximum supply voltage (Vsup)40 V
Minimum supply voltage (Vsup)4.7 V
Nominal supply voltage (Vsup)10 V
surface mountNO
technologyCMOS
Temperature levelOTHER
Terminal surfaceTIN LEAD
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
width7.62 mm
