MPB-05S
Series
Miniature PCB-Mount,
5W, Open Frame
AC/DC Power Supplies
Electrical Specifications
Key Features:
•
5W Output Power
•
Universal 85-264 AC Input
•
EN 60950 Approved (UL)
•
PCB Mountable
•
Meets IEC Safety Class II
•
Meets EN 55022 B
•
Efficiency To 80%
•
>200 kHour MTBF
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Input
Parameter
Input Voltage Range
Input Frequency
Input Filter
Input Current
Inrush Current
Safety Ground Leakage Current
Conditions
Min.
Typ.
Universal
85
127
47
Meets EN 55022 Class B
See Model Selection Guide
Cold Start, 115 VAC
Cold Start, 230 VAC
264 VAC
Max.
264
373
63
Units
VAC
VDC
Hz
25.0
40.0
0.25
Max.
A Pk
mA
Units
%
%
%
%
mSec
%/°C
%
Output
Parameter
Output Voltage/Current
Output Voltage Tolerance
Line Regulation
Load Regulation
Ripple & Noise (20 MHz)
Hold-Up Time
Temperature Coefficient
Short Circuit Protection
Overload Protection
Conditions
Min.
Typ.
See Model Selection Guide
See Note 1
±1.0
Vin = 100 VAC to 240 VAC
±0.5
Iout = 10% to 100%
±1.0
See Note 2
±1.0
115 VAC
8
230 VAC
60
±0.05
Continuous (Autorecovery)
170
Conditions
Input to Output
500 VDC
Conducted
Electrostatic Discharge (ESD)
RF Field Susceptibility
Electrical Fast Transients/Bursts On Mains
Surge
Fixed
Conditions
Min.
3,000
Typ.
General
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
EMI/RFI
Units
VAC
100
M
1,100
pF
EN 55022; EN 61000-3-2, -3
IEC/EN 61000-4-2, -6, -8, -11
IEC/EN 61000-4-3
IEC/EN 61000-4-4
IEC/EN 61000-4-5
66
kHz
Units
°C
°C
%
Max.
EMC Compliance
Switching Frequency
Environmental
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
Parameter
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Physical
Size
Weight
Min.
Typ.
Max.
0
+25
+70
-20
+85
Free Air Convection (See Derating Curve)
RH, Non-condensing
93
Ambient
2.16 x 1.378 x 0.827 Inches (55.0 x 35.0 x 21.0 mm)
1.23 Oz (0.035 kg)
Conditions
Min.
Typ.
Max.
Units
MIL HDBK 217F, 25°C, Gnd Benign
200
kHours
UL 60950, EN 60950
Sinusoidal 50~500 Hz, 3.0 Grms, Period of 30 min each along X, Y & Z Axis
Reliability Specifications
Parameter
MTBF
Safety Standards
Vibration
www.micropowerdirect.com
Model Selection Guide
Model
Number
MPB-05S-03
MPB-05S-05
MPB-05S-09
MPB-05S-12
MPB-05S-15
MPB-05S-18
MPB-05S-24
Input
Current
(A)
115
VAC
0.15
0.15
0.15
0.15
0.15
0.15
0.15
230
VAC
0.07
0.07
0.07
0.07
0.07
0.07
0.07
Voltage
(VDC)
www.micropowerdirect.com
Output
Current
(A)
Rated
1.25
1.00
0.55
0.42
0.33
0.28
0.23
% Min.
0.00
0.00
0.00
0.00
0.00
0.00
0.00
Max
Output
Power
(W)
Efficiency
(%, Typ)
3.3
5.0
9.0
12.0
15.0
18.0
24.0
4.12
5.00
5.00
5.00
5.00
5.00
5.50
70
73
76
77
78
78
80
Other Models May Be Available. Contact The Factory For Details
Notes:
1. Output voltage tolerance is measured at nominal input and 75% load.
2. Output ripple is measured at 20 MHz bandwidth using 0.1
µF
and 10
µF
capacitors connected in parallel as close to the power supply terminals
as possible.
3. These units will operate at no load without damage. For most appli-
cations however,
MPD
recommends that a minimum load always be
used. Contact the factory for more information.
4. Each unit includes an input fuse (250V/1A). Since this fuse is not field
replaceable, it is recommended that an external fuse of the same size
be used on the input of the power supply for protection.
Derating Curve
Mechanical Dimensions
Pin Connections
Pin
1
2
3
4
Description
AC-Neutral
AC-Line
-V Output
+V Output
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx =
±
0.02 (
±
0.50)
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
