LC0343-GGGG
LC0343-YEYERR
LC0343-RERERERE
Circuit board indicator — 3mm Dia LED, Four-level
TECHNICAL DATA
DATA SHEET 3520, REV. -
Notes: All dimensions are in mm (inch)
Tolerance is
±
0.25 mm (0.01”) unless otherwise specified
Electro-optical Characteristic: (T
a
=25
°C)
Wave-
Chip
Part No.
length
Material
Color
(nm)
LC0343-GGGG
A=GaP
B=GaP
C=GaP
D=GaP
A=GaAsP
B=GaAsP
C=GaP
D=GaP
A=GaAsP
B=GaAsP
C=GaAsP
D=GaAsP
Green
Green
Green
Green
Yellow
Yellow
Red
Red
Red
Red
Red
Red
565
565
565
565
585
585
700
700
635
635
635
635
Lens
Green Diff.
Green Diff.
Green Diff.
Green Diff.
Yellow Diff.
Yellow Diff.
Red Diff.
Red Diff.
Red Diff.
Red Diff.
Red Diff.
Red Diff.
Vf @
20mA
Typ.
2.1
2.1
2.1
2.1
2.1
2.1
2.1
2.1
2.0
2.0
2.0
2.0
Iv (mcd)
@20mA
Typ.
12.5
12.5
12.5
12.5
12.5
12.5
5.0
5.0
20.0
20.0
20.0
20.0
Viewing
Angle
o
2θ
1/2
( )
60
60
60
60
60
60
60
60
60
60
60
60
LC0343-
YEYERR
LC0343-
RERERERE
Features
•
Available with a variety of LEDs
•
Housing material UL94V-0 rated
•
Black housing enhances contrast
•
High reliability - life measured in years
•
Vibration and shock resistant
•
Housing assures proper LED alignment
•
221 West Industry Court
•
Deer Park, NY 11729-4681
•
Phone: (631) 586-7600
•
Fax: (631) 242-9798
•
http://www.sensitron.com
•
E-Mail: sales@sensitron.com
DISCLAIMER:
1- The information given herein, including the specifications and dimensions, is subject to change without prior not ice to
improve product characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales
department for the latest version of the datasheet(s).
2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation,
traffic equipment, medical equipment , and safety equipment) , safety should be ensured by using semiconductor devices
that feature assured safety or by means of users’ fail-safe precautions or other arrangement .
3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other
cause during operation of the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no
responsibility for any intellectual property claims or any other problems that may result from applications of information,
products or circuits described in the datasheets.
4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage
resulting from use at a value exceeding the absolute maximum rating.
5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron
Semiconductor.
6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written
permission of Sensitron Semiconductor.
7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their
application will hinder maintenance of international peace and safety nor are they to be applied to that purpose by their
direct purchasers or any third party. When exporting these products (technologies), the necessary procedures are to be
taken in accordance with related laws and regulations.
•
