Copper Compression
Connectors
BYSM Line
DIN 46341/T1
Non-insulated copper brazed
butt splices per DIN 46341/T1
form B
Description
• Range of copper brazed splices joining
wires from 0,1 - 150 mm
2
WIRE
RANGE
INTERNALLY
BEVELED ENDS
ELECTRO-TIN
PLATED
Construction
• Electrolytic copper sheet, tinplated
Performance
• Heat resistant up to +125ºC
Tooling
• The indicated numbers in the tooling table
refer to pages 48 - 63.
Mechanical tools
mm
2
Cat. No.
d
a
Tooling
number
MRD29
Hydraulic tools
Y35/Y35BH
Y500CT
Y750/Y750
BCT500
BAT35/BAT750
0,1 - 0,5
0,25 - 1,5
1 - 2,5
>4 - 6
>6 - 10
>10 - 16
>16 - 25
>25 - 35
>35 - 50
>50 - 70
>70 - 95
>95 - 120
>120 - 150
BYSM05
BYSM1
BYSM025
BYSM6
BYSM10
BYSM16
BYSM25
BYSM35
BYSM50
BYSM70
BYSM95
BYSM120
BYSM150
1,2
1,6
2,3
3,6
4,5
5,8
7,5
9,0
11,0
13,0
15,0
16,5
19,0
5,0
7,0
7,0
7,0
9,0
10,0
11,0
12,0
16,0
18,0
20,0
22,0
24,0
Consult
1 - 22
1 - 22
1 - 14 - 22
14
50NKC2
N
50NKC1
I
N
WVB10
WVB16
50PE0670C
WPQS
I
N
UVB10
I
14
14
WVB25
WVB35
WVB50
UVB25
UVB35
WVB95
WVB120
WPQ6S
50NKC3
WVB70
UVB70
UVB95
UVB120
UVB150
N= Nest die, I= Indentor
35
Y35P1PQ7S
Y35P1PQ6S
50NKC1
UVB50
Y35P1PQS
14
UVB16
