IMC0805ER3N9C01

Description
General Fixed Inductor, 1 ELEMENT, 0.0039 uH, CERAMIC-CORE, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0805, HALOGEN FREE AND ROHS COMPLIANT
CategoryPassive components    inductor
File Size80KB,3 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric View All

IMC0805ER3N9C01 Overview

General Fixed Inductor, 1 ELEMENT, 0.0039 uH, CERAMIC-CORE, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0805, HALOGEN FREE AND ROHS COMPLIANT

IMC0805ER3N9C01 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerVishay
package instruction0805
Reach Compliance Codeunknown
ECCN codeEAR99
uppercase and lowercase codes0805
structureWirewound
core materialCERAMIC
DC Resistance0.06 Ω
Nominal inductance(L)0.0039 µH
Inductor ApplicationsRF INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
JESD-609 codee4
Number of functions1
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package height1.2 mm
Package length2 mm
Package formSMT
Package width1.25 mm
method of packingTR, 7 Inch
Minimum quality factor (at nominal inductance)60
Maximum rated current0.6 A
self resonant frequency6000 MHz
seriesIMC-0805-01
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldNO
special characteristicsINDUCTANCE TOLERANCE IS 0.2 NANO HENRY, Q MEASURED AT 1000 MHZ
surface mountYES
Terminal surfaceGold (Au) - with Nickel (Ni) barrier
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Test frequency250 MHz
Tolerance5.129%
IMC-0805-01
Vishay Dale
Wirewound, Surface Mount Inductors
FEATURES
High self-resonant frequency values
High Q values at higher frequencies
Wirewound construction
Compatible with vapor phase and infrared reflow
soldering
• Tape and reel packaging for automatic handling,
2000/reel
• Compliant to RoHS Directive 2002/95/EC
• Halogen-free according to IEC 61249-2-21 definition
STANDARD ELECTRICAL SPECIFICATIONS
IND.
(nH)
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10 000
TEST
FREQ.
(MHz)
L
Q
250 1000
250 1000
250 1000
250 1000
250 1000
250 1000
250 1000
250 1000
250 500
250 500
250 500
250 500
250 500
250 500
250 500
250 500
200 500
200 500
200 500
150 500
150 500
150 250
100 250
100 250
100 250
100 250
100 250
100 250
25.2 100
25.2 100
25.2 100
25.2 100
25.2 50
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
7.96 7.96
2.52 2.52
Q
MIN.
50
35
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
50
50
50
50
45
45
45
45
45
35
35
35
15
15
15
15
15
15
15
15
15
15
15
10
SRF
MIN.
(MHz)
6000
6000
6000
6000
5800
5800
5500
5500
4800
4100
3600
3400
3300
2600
2400
2100
1700
1600
1450
1350
1200
1100
950
900
860
850
800
780
375
340
188
215
200
200
200
120
110
100
70
60
50
45
45
40
40
DCR RATED DC
MAX. CURRENT
()
(mA)
0.06
800
0.08
800
0.08
800
0.06
600
0.06
600
0.08
600
0.06
600
0.06
600
0.08
600
0.08
600
0.08
600
0.08
600
0.10
600
0.12
600
0.15
500
0.18
500
0.15
500
0.25
500
0.27
500
0.32
500
0.43
500
0.48
500
0.56
400
0.78
400
1.00
400
1.46
350
1.65
300
2.20
210
0.95
500
1.10
450
1.20
400
1.50
300
2.13
180
2.60
150
2.90
130
3.00
120
3.10
110
3.50
100
2.30
210
2.50
200
2.80
180
3.00
160
3.20
130
3.50
120
5.00
80
TOL.
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
0.3 nH, 0.2 nH
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5 %, 2 %
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
ELECTRICAL SPECIFICATIONS
Inductance Range:
2.2 nH to 10 000 nH
Inductance and Tolerance:
0.3 nH for 2.2 nH to 4.7 nH,
± 5 % for 5.6 nH to 10 000 nH
Operating Temperature:
- 40 °C to + 125 °C
Core Material:
Ceramic from 2.2 nH to 390 nH; Ferrite from
470 nH to 10 000 nH
TEST EQUIPMENT
• Inductance and Q measured on HP4286A (2.2 nH to
390 nH) and HP4285A (470 nH to 10 000 nH)
• SRF is measured on HP8753E
• DCR ismeasured on HP4338B
DIMENSIONS
in inches [millimeters]
0.079 ± 0.008
[2.00 ± 0.2]
0.050 ± 0.008
[1.25 ± 0.2]
0.016 ± 0.008
[0.40 ± 0.2]
0.02 [0.5]
0.048 ± 0.008
[1.20 ± 0.2]
DESCRIPTION
IMC-0805-01
10 nH
±5%
ER
e4
(1)
MODEL
INDUCTANCE VALUE
INDUCTANCE TOLERANCE
PACKAGE CODE
JEDEC LEAD (Pb)-FREE STANDARD
Note
(1)
For parts within 2.2 nH to 390 nH please use e4 for JEDEC lead (Pb)-free standard. For parts within 470 nH to 10 000 nH please use e3 for
JEDEC lead (Pb)-free standard.
GLOBAL PART NUMBER
I
M
C
0
8
SIZE
0
5
E
R
1
0
INDUCTANCE
VALUE
N
J
TOL.
0
1
PRODUCT FAMILY
PACKAGE
CODE
SERIES
Document Number: 34115
Revision: 24-Feb-11
For technical questions, contact:
magnetics@vishay.com
www.vishay.com
1
