IMSG332F-11S datasheet, PDF - EEWORLD Datasheet

IMSG332F-11S: Description1280X1024 PIXELS CRT GRPH DSPL CTLR, CQFP100, CAVITY-UP, CERAMIC, QFP-100; CategoryThe embedded processor and controller Microcontrollers and processors; File Size233KB，8 Pages; ManufacturerSTMicroelectronics; Websitehttp://www.st.com/

Download Datasheet Parametric Compare View All

IMSG332F-11S Overview

1280X1024 PIXELS CRT GRPH DSPL CTLR, CQFP100, CAVITY-UP, CERAMIC, QFP-100

Parameter Name	Attribute value
Maker	STMicroelectronics
Parts packaging code	QFP
package instruction	CAVITY-UP, CERAMIC, QFP-100
Contacts	100
Reach Compliance Code	compliant
Address bus width	24
show configuration	1280 X 1024 PIXELS
External data bus width	24
JESD-30 code	R-CQFP-G100
length	20 mm
Number of terminals	100
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QFP
Package shape	RECTANGULAR
Package form	FLATPACK
Certification status	Not Qualified
Maximum seat height	3.4 mm
Nominal supply voltage	5 V
surface mount	YES
technology	MOS
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	QUAD
width	14 mm
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, CRT GRAPHICS DISPLAY

	IMSG332F-11S	IMSG332F-10S	IMSG332F-85S
Description	1280X1024 PIXELS CRT GRPH DSPL CTLR, CQFP100, CAVITY-UP, CERAMIC, QFP-100	1280X1024 PIXELS CRT GRPH DSPL CTLR, CQFP100, CAVITY-UP, CERAMIC, QFP-100	1280X1024 PIXELS CRT GRPH DSPL CTLR, CQFP100, CAVITY-UP, CERAMIC, QFP-100
Maker	STMicroelectronics	STMicroelectronics	STMicroelectronics
Parts packaging code	QFP	QFP	QFP
package instruction	CAVITY-UP, CERAMIC, QFP-100	CAVITY-UP, CERAMIC, QFP-100	CAVITY-UP, CERAMIC, QFP-100
Contacts	100	100	100
Reach Compliance Code	compliant	compliant	not_compliant
Address bus width	24	24	24
show configuration	1280 X 1024 PIXELS	1280 X 1024 PIXELS	1280 X 1024 PIXELS
External data bus width	24	24	24
JESD-30 code	R-CQFP-G100	R-CQFP-G100	R-CQFP-G100
length	20 mm	20 mm	20 mm
Number of terminals	100	100	100
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED
encapsulated code	QFP	QFP	QFP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	FLATPACK	FLATPACK	FLATPACK
Certification status	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	3.4 mm	3.4 mm	3.4 mm
Nominal supply voltage	5 V	5 V	5 V
surface mount	YES	YES	YES
technology	MOS	MOS	MOS
Terminal form	GULL WING	GULL WING	GULL WING
Terminal pitch	0.65 mm	0.65 mm	0.65 mm
Terminal location	QUAD	QUAD	QUAD
width	14 mm	14 mm	14 mm
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, CRT GRAPHICS DISPLAY	DISPLAY CONTROLLER, CRT GRAPHICS DISPLAY	DISPLAY CONTROLLER, CRT GRAPHICS DISPLAY
