MCC
Micro Commercial Components
TM
omponents
20736 Marilla
Street Chatsworth
!"#
$
% !"#
MPSA06
•
Features
Halogen
free available upon request by adding suffix "-HF"
NPN Silicon Epitaxial Planar Transistor for switching and
amplifier applications
Epoxy meets UL 94 V-0 flammability rating
Moisure Sensitivity Level 1
As complementary type,the PNP transistor is MPSA56
Lead Free Finish/RoHS Compliant ("P" Suffix designates
RoHS Compliant. See ordering information)
•
•
•
•
•
NPN Small
Signal Transistor
625 mW
TO-92
A
E
Mechanical Data
Marking:MPSA06
Weight: 0.18 grams (Approx.)
Maximum Ratings @ 25
o
C Unless Otherwise Specified
B
Characteristic
Collect to Base Voltage
Collect to Emitter Voltage
Emitter to Base Voltage
Collect Current
Total Power Dissipation @ T
A
=25 C
Total Power Dissipation @ T
C
=25 C
Thermal Resistance Junction to
Ambient
Junction Temperature
Storage Temperature
o
o
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
tot
P
tot
R
q
JA
Value
80
80
4.0
500
625
1.5
200
150
-55 to 150
Unit
V
V
V
mA
mW
W
o
C
C/W
o
o
T
j
T
STG
o
C
C
D
Electrical Characteristics @ 25 C Unless Otherwise Specified
Charateristic
Collector Cut-off Current
Collector to Emitter
Saturatuion Voltage
DC Current Gain
S y m b o l Min
I
C B O
V
CE(sat)
h
FE
f
T
V
(BR)CEO
V
(BR)EBO
V
BE(ON)
100
100
100
80
4
1.2
MHz
V
V
V
Max Unit
100
0.25
nA
V
Test Cond.
V
CB
=80V, I
E
= 0
I
C
=100mA, I
B
= 1 0 m A
E
E
B
C
B
C
G
V
CE
=1V, I
C
= 1 0 m A
V
CE
=1V, I
C
=100mA
V
CE
=2V, I
C
=20mA,
f=100MHz
I
C
=1mA, I
B
= 0
I
E
=100 uA, I
C
= 0
I
C
=10mA, I
B
= 1 m A
DIM
A
B
C
D
E
G
INCHES
MIN
.175
.175
.500
.016
.135
.095
.173
STRAIGHT LEAD BENT LEAD
BULK PACK
AMMO PACK
DIMENSIONS
MM
MAX
.185
.185
---
.020
.145
.105
.220
MIN
4.45
4.45
12.70
0.41
3.43
2.42
4.40
MAX
4.70
4.70
---
0.63
3.68
2.67
5.60
NOTE
Gain Bandwidth Product
Collector-Emitter
Breakdown Voltage
Emitter-Base
Breakdown Voltage
Base-Emitter ON
Voltage
Straight Lead
Bent Lead
* For ammo packing detailed specification, click here to visit our website
of product packaging for details.
Note
: Valid provided that leads are kept at ambient temperature.
www.mccsemi.com
1 of 2
Revision:
D
2013/01/01
MCC
Micro Commercial Components
TM
Ordering Information :
Device
Part Number-AP
Part Number-BP
Note : Adding "-HF" suffix for halogen free, eg. Part Number-AP-HF
Packing
Ammo Packing:
20Kpcs/Carton
Bulk:
100Kpcs/Carton
***IMPORTANT NOTICE***
Micro Commercial Components Corp.
reserves the right to make changes without further notice to any product herein to
make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components
Corp .
does not assume any liability arising out of the application or use of any product described herein; neither does it
convey any license under its patent rights ,nor the rights of others . The user of products in such applications shall assume all
risks of such use and will agree to hold
Micro Commercial Components Corp .
and all the companies whose products are
represented on our website, harmless against all damages.
***LIFE SUPPORT***
MCC's products are not authorized for use as critical components in life support devices or systems without the express written
approval of Micro Commercial Components Corporation.
***CUSTOMER AWARENESS***
Counterfeiting of semiconductor parts is a growing problem in the industry. Micro Commercial Components (MCC) is taking
strong measures to protect ourselves and our customers from the proliferation of counterfeit parts. MCC strongly encourages
customers to purchase MCC parts either directly from MCC or from Authorized MCC Distributors who are listed by country on
our web page cited
below.
Products customers buy either from MCC directly or from Authorized MCC Distributors are genuine
parts, have full traceability, meet MCC's quality standards for handling and storage.
MCC will not provide any warranty
coverage or other assistance for parts bought from Unauthorized Sources.
MCC is committed to combat this global
problem and encourage our customers to do their part in stopping this practice by buying direct or from authorized
distributors.
www.mccsemi.com
Revision:
D
2 of 2
2013/01/01
