TIGER ELECTRONIC CO.,LTD
DF005 THRU DF10
Single Phase 1.0 AMPS.
Silicon Bridge Rectifiers
Voltage Range
50 to 1000 Volts
Current
1.0 Amperes
DB
Features
•
UL Recognized File # E-230084
•
Ideal for printed circuit board
•
Reliable low cost construction technique
results in inexpensive product
•
High temperature soldering guaranteed:
260
℃
/ 10 seconds / 0.375” ( 9.5mm )
lead length at 5 lbs., ( 2.3 kg ) tension
-
+
.255(6.5) .315(8.0)
.245(6.2) .285(7.24)
.350(8.9)
.300(7.6)
~
.205(5.2)
.195(5.0)
~
.013(0.33)
.0088(0.22)
Mechanical Data
•
Case: Molded plastic
•
Lead: solder plated
•
Polarity: As marked
.08(2.03)
.05(1.27)
.335(8.51)
.320(8.13)
.045(1.14)
.035(0.89)
.130(3.30)
.120(3.05)
.185(4.69)
.150(3.81)
.023(0.58)
.018(0.46)
.075(1.90)
.055(1.39)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25
℃
ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC blocking Voltage
DF005
DF01
100
70
100
DF02
200
140
200
DF04
400
280
400
1.0
50
1.1
10
500
40
15
-55 to +150
-55 to +150
DF06
600
420
600
DF08
800
560
800
DF10
1000
700
1000
UNITS
V
V
V
A
A
V
μA
℃/W
℃
℃
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
Rθ
JA
Rθ
JL
T
J
T
STG
50
35
50
Maximum Average Forward Rectified Current
@T
A
= 40℃
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage @ 1.0A
Maximum DC Reverse Current @ TA=25℃
rated DC blocking voltage per leg TA = 125℃
Typical Thermal Resistance (Note)
Operating Temperature Range
Storage Temperature Range
NOTE：
Thermal Resistance from Junction to Ambient and from Junction to Lead Mounted on P.C.B.with
0.47×0.47”(12×12mm) Copper
Pads.
