SCREW TERMINAL ALUMINUM ELECTROLYTIC CAPACITORS
LSC
LSC
SERIES
105℃ 5000 hours, High Ripple Current, Screw Terminal Type
◆FEATURES
・
Load Life : 105℃ 5000 hours
・
RoHS compliance.
◆SPECIFICATIONS
Items
Category Temperature Range
Rated Voltage Range
Capacitance Tolerance
Characteristics
−25∼＋105℃
350∼450Vdc
±20％
（20℃，
120Hz）
I＝3
CV or 5mA whichever is smaller.(After 5 minutes application of rated voltage)
Leakage Current(MAX)
I＝
Leakage Current
(μA)
(tanδ)
Dissipation Factor(MAX)
C＝
Capacitance
(μF)
V＝
Rated Voltage
(Vdc)
0.25（20℃，
120Hz）
After applying rated voltage with rated ripple current for 5000 hours at 105℃,
the capacitors shall meet the following requirements.
Endurance
Capacitance Change
Dissipation Factor
Leakage Current
Within ±20％ of the initial value.
Not more than 200％ of the specified value.
Not more than the specified value.
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency
（Hz）
Coefficient
60 50）120 100） 300
（
（
0.80
1.00
1.17
500
1.23
1k
1.30
10k≦
1.40
◆PART NUMBER
□□□
Rated Voltage
LSC
Series
□□□□□
Capacitance
M
Capacitance Tolerance
□□□
Option
□□
Clamp Code
D×L
Case Size
◆Dimensions in mm (not to scale)
〈I type〉
Plate
Mounting
Clamp
Case
Sleeve
Screw
Terminal Bolt
W2±2
Clamp
Bolt
W3
W4
〈Y type〉
Vent
Plate
W1±2
Mounting
Clamp
Sleeve
Case Screw
Bolt
Terminal
Vent
Clamp
Bolt
W3
W4
W2±2
W1±2
φD W1
I type
W5
W2
W3
W4
7.0
6.0
6.0
8.0
7.0
8.0
W5
(mm)
F
64 40.0 45.0 4.5
77 47.0 53.0 4.5
90 54.0 60.0 4.5
64 38.0 43.0 4.5
77 44.5 49.0 4.5
90 50.8 56.0 4.5
12 28.2
12 31.4
14 31.4
14 28.2
14 31.4
16 31.4
D±2
D±2
F±1
F±1
M5 P=0.8Bolt
L±3
W5
M5 P=0.8Bolt
L±3
Y type
SCREW TERMINAL ALUMINUM ELECTROLYTIC CAPACITORS
LSC
◆STANDARD SIZE
Rated Voltage Capacitance
（μF）
(Vdc)
Size
Rated Ripple Current
φDXL ㎜） (A.r.m.s 105℃,120Hz)
（
Rated Voltage Capacitance
（μF）
(Vdc)
Size
Rated Ripple Current
φDXL ㎜） (A.r.m.s 105℃,120Hz)
（
350
400
2700
3300
3900
3900
4700
4700
5600
5600
5600
6800
6800
6800
8200
8200
8200
10000
10000
12000
12000
15000
2200
2700
3300
3300
3900
3900
4700
4700
4700
5600
5600
5600
6800
6800
6800
8200
8200
10000
10000
12000
64×104
64×114
64×129
77×101
64×149
77×111
64×174
77×126
90×104
64×204
77×151
90×119
64×244
77×171
90×134
77×206
90×159
77×241
90×184
90×219
64×104
64×114
64×134
77×101
64×154
77×116
64×179
77×131
90×104
64×209
77×151
90×119
64×249
77×176
90×139
77×211
90×159
77×246
90×189
90×219
12.5
13.9
15.4
17.0
17.3
19.4
19.4
21.6
24.0
21.9
24.7
27.2
24.7
27.6
30.5
31.4
34.9
35.2
39.3
45.3
11.6
12.9
14.7
16.4
16.4
18.2
18.4
20.4
22.5
20.5
22.9
25.3
23.2
25.8
28.8
29.2
32.4
33.0
37.0
41.7
450
1800
2200
2700
2700
3300
3300
3900
3900
3900
4700
4700
4700
5600
5600
5600
6800
6800
8200
8200
10000
64×104
64×114
64×134
77×101
64×154
77×116
64×179
77×131
90×104
64×209
77×151
90×119
64×244
77×176
90×134
77×206
90×159
77×241
90×184
90×219
10.0
11.5
13.1
14.0
14.8
15.8
16.4
17.6
19.4
18.4
19.8
21.9
20.6
22.2
24.5
25.0
28.0
28.1
31.6
36.1
◆Tightening torque of bolt and Permissible current of terminal.
Clamp Bolt
M3
M4
Recommended Tightening torque
0.6 [N m]
・
1.3 [N m]
・
M5
Terminal
Recommended Tightening torque
(Permissible Range)
2.2(1.5∼3.2) [N m]
・
Permissible Current
of Terminal
60Arms
