LOW COST - HIGH PERFORMANCE VOLTAGE CONTROLLED OSCILLATOR

Preview

Download Datasheet

View All

V910ME13

9939 Via Pasar • San Diego, CA 92126

TEL (858) 621-2700 FAX (858) 621-2722

VOLTAGE CONTROLLED OSCILLATOR

Rev A1

PHASE NOISE (1 Hz BW, typical)

-50

-60

-70

-80

-90

FEATURES

• Frequency Range: 4200 - 4400

• Tuning Voltage:

2-10 Vdc

• MINI-14S-L - Style Package

APPLICATIONS

• Microwave Radios

• Satellite Communications

• Direct Broadcast

PERFORMANCE SPECIFICATIONS

Oscillation Frequency Range

-100

MHz

-110

-120

-130

-140

1000

10000

100000

VALUE

4200

4400

-86

-27

2-10

0.5±3.5

<11

-40 to 85

MINI-14S-L

UNITS

MHz

dBc/Hz

dBc

Vdc

MHz/V

dBm

Phase Noise @ 10 kHz offset (1 Hz BW, typ.)

Harmonic Suppression (2nd, typ.)

Tuning Voltage

Tuning Sensitivity (avg.)

Power Output

Load Impedance

Input Capacitance (max.)

Pushing

Pulling (14 dB Return Loss, Any Phase)

MHz/V

MHz

°C

Operating Temperature Range

Package Style

POWER SUPPLY REQUIREMENTS

Supply Voltage (Vcc, nom.)

Supply Current (Icc, typ.)

APPLICATION NOTES

Vdc

All specifications are typical unless otherwise noted and subject to change without notice.

•

AN-100/1 : Mounting and Grounding of VCOs

•

AN-102 : Proper Output Loading of VCOs

•

AN-107 : How to Solder Z-COMM VCOs

NOTES:

Phase Noise @ 100 kHz offset (1 Hz BW, typ.): -109 dBc/Hz

Page 1
