BUK7Y65-100E
8 May 2013
PA
K
56
N-channel 100 V, 65 mΩ standard level MOSFET in LFPAK56
Product data sheet
1. General description
Standard level N-channel MOSFET in an LFPAK56 (Power SO8) package using
TrenchMOS technology. This product has been designed and qualified to AEC Q101
standard for use in high performance automotive applications.
2. Features and benefits
•
•
•
•
Q101 compliant
Repetitive avalanche rated
Suitable for thermally demanding environments due to 175 °C rating
True standard level gate with V
GS(th)
rating of greater than 1 V at 175 °C
3. Applications
•
•
•
•
12 V, 24 V and 48 V Automotive systems
Motors, lamps and solenoid control
Transmission control
Ultra high performance power switching
4. Quick reference data
Table 1.
Symbol
V
DS
I
D
P
tot
R
DSon
Quick reference data
Parameter
drain-source voltage
drain current
total power dissipation
Conditions
T
j
≥ 25 °C; T
j
≤ 175 °C
V
GS
= 10 V; T
mb
= 25 °C;
Fig. 1
T
mb
= 25 °C;
Fig. 2
V
GS
= 10 V; I
D
= 5 A; T
j
= 25 °C;
Fig. 11
Min
-
-
-
Typ
-
-
-
Max
100
19
64
Unit
V
A
W
Static characteristics
drain-source on-state
resistance
gate-drain charge
-
44
65
mΩ
Dynamic characteristics
Q
GD
V
GS
= 10 V; I
D
= 5 A; V
DS
= 80 V;
T
j
= 25 °C;
Fig. 13; Fig. 14
-
7
-
nC
Scan or click this QR code to view the latest information for this product
NXP Semiconductors
BUK7Y65-100E
N-channel 100 V, 65 mΩ standard level MOSFET in LFPAK56
5. Pinning information
Table 2.
Pin
1
2
3
4
mb
Pinning information
Symbol Description
S
S
S
G
D
source
source
source
gate
mounting base; connected to
drain
1 2 3 4
G
mbb076
Simplified outline
mb
Graphic symbol
D
S
LFPAK56; Power-
SO8 (SOT669)
6. Ordering information
Table 3.
Ordering information
Package
Name
BUK7Y65-100E
LFPAK56;
Power-SO8
Description
Plastic single-ended surface-mounted package (LFPAK56;
Power-SO8); 4 leads
Version
SOT669
Type number
7. Marking
Table 4.
Marking codes
Marking code
76510E
Type number
BUK7Y65-100E
8. Limiting values
Table 5.
Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).
Symbol
V
DS
V
DGR
V
GS
I
D
Parameter
drain-source voltage
drain-gate voltage
gate-source voltage
drain current
Conditions
T
j
≥ 25 °C; T
j
≤ 175 °C
R
GS
= 20 kΩ
T
j
≤ 175 °C; DC
T
mb
= 25 °C; V
GS
= 10 V;
Fig. 1
T
mb
= 100 °C; V
GS
= 10 V;
Fig. 1
I
DM
P
tot
T
stg
BUK7Y65-100E
Min
-
-
-20
-
-
-
-
-55
Max
100
100
20
19
13.4
76
64
175
Unit
V
V
V
A
A
A
W
°C
peak drain current
total power dissipation
storage temperature
T
mb
= 25 °C; pulsed; t
p
≤ 10 µs;
Fig. 4
T
mb
= 25 °C;
Fig. 2
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2013. All rights reserved
Product data sheet
8 May 2013
2 / 13
NXP Semiconductors
BUK7Y65-100E
N-channel 100 V, 65 mΩ standard level MOSFET in LFPAK56
Symbol
T
j
I
S
I
SM
E
DS(AL)S
Parameter
junction temperature
Conditions
Min
-55
Max
175
Unit
°C
Source-drain diode
source current
peak source current
T
mb
= 25 °C
pulsed; t
p
≤ 10 µs; T
mb
= 25 °C
I
D
= 19 A; V
sup
≤ 100 V; R
GS
= 50 Ω;
V
GS
= 10 V; T
j(init)
= 25 °C; unclamped;
Fig. 3
[1]
[2]
20
-
-
19
76
A
A
Avalanche ruggedness
non-repetitive drain-source
avalanche energy
[1][2]
-
25.3
mJ
Single-pulse avalanche rating limited by maximum junction temperature of 175 °C.
Refer to application note AN10273 for further information.
003aai670
I
D
(A)
120
P
der
(%)
80
03aa16
15
10
40
5
0
0
30
60
90
120
150
T
j
(°C)
180
0
0
50
100
150
T
mb
(°C)
200
Fig. 1.
Continuous drain current as a function of
mounting base temperature
Fig. 2.
Normalized total power dissipation as a
function of mounting base temperature
BUK7Y65-100E
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2013. All rights reserved
Product data sheet
8 May 2013
3 / 13
NXP Semiconductors
BUK7Y65-100E
N-channel 100 V, 65 mΩ standard level MOSFET in LFPAK56
10
2
I
AL
(A)
10
003aai671
1
(1)
(2)
10
-1
(3)
10
-2
10
-3
10
-2
10
-1
1
t
AL
(ms)
10
Fig. 3.
Avalanche rating; avalanche current as a function of avalanche time
I
D
(A)
10
2
Limit R
DSon
= V
DS
/ I
D
t
p
= 10 us
10
100 us
003aaj807
1
DC
1 ms
10 ms
100 ms
10
-1
10
-2
1
10
10
2
V
DS
(V)
10
3
Fig. 4.
Safe operating area; continuous and peak drain currents as a function of drain-source voltage
9. Thermal characteristics
Table 6.
Symbol
R
th(j-mb)
Thermal characteristics
Parameter
thermal resistance
from junction to
mounting base
Conditions
Fig. 5
Min
-
Typ
-
Max
2.31
Unit
K/W
BUK7Y65-100E
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2013. All rights reserved
Product data sheet
8 May 2013
4 / 13
NXP Semiconductors
BUK7Y65-100E
N-channel 100 V, 65 mΩ standard level MOSFET in LFPAK56
Z
th(j-mb)
(K/W)
10
003aai358
1
δ = 0.5
0.2
0.1
10
-1
0.05
0.02
single shot
P
δ=
t
p
T
t
p
10
-2
10
-6
10
-5
10
-4
10
-3
10
-2
10
-1
t
T
t
p
(s)
1
Fig. 5.
Transient thermal impedance from junction to mounting base as a function of pulse duration
10. Characteristics
Table 7.
Symbol
V
(BR)DSS
Characteristics
Parameter
drain-source
breakdown voltage
gate-source threshold
voltage
Conditions
I
D
= 250 µA; V
GS
= 0 V; T
j
= 25 °C
I
D
= 250 µA; V
GS
= 0 V; T
j
= -55 °C
I
D
= 1 mA; V
DS
= V
GS
; T
j
= 25 °C;
Fig. 9; Fig. 10
I
D
= 1 mA; V
DS
= V
GS
; T
j
= -55 °C;
Fig. 9
I
D
= 1 mA; V
DS
= V
GS
; T
j
= 175 °C;
Fig. 9
I
DSS
drain leakage current
V
DS
= 100 V; V
GS
= 0 V; T
j
= 25 °C
V
DS
= 100 V; V
GS
= 0 V; T
j
= 175 °C
I
GSS
gate leakage current
V
GS
= 20 V; V
DS
= 0 V; T
j
= 25 °C
V
GS
= -20 V; V
DS
= 0 V; T
j
= 25 °C
R
DSon
drain-source on-state
resistance
V
GS
= 10 V; I
D
= 5 A; T
j
= 25 °C;
Fig. 11
V
GS
= 10 V; I
D
= 5 A; T
j
= 175 °C;
Fig. 11; Fig. 12
Dynamic characteristics
Q
G(tot)
Q
GS
Q
GD
total gate charge
gate-source charge
gate-drain charge
I
D
= 5 A; V
DS
= 80 V; V
GS
= 10 V;
T
j
= 25 °C;
Fig. 13; Fig. 14
-
-
-
17.8
3.4
7
-
-
-
nC
nC
nC
-
-
-
-
-
-
0.03
-
2
2
44
-
1
500
100
100
65
180
µA
µA
nA
nA
mΩ
mΩ
1
-
-
V
-
-
4.5
V
Min
100
90
2.4
Typ
-
-
3
Max
-
-
4
Unit
V
V
V
Static characteristics
V
GS(th)
BUK7Y65-100E
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2013. All rights reserved
Product data sheet
8 May 2013
5 / 13
