SMSC/C
Small Miniature
Suppression Coils
Miniature Suppression Coil
0.8
17
87
5.5
Specifications & Standard Values
Ordering
Inductance
Code
L
(
µH
)
SMSC/C-1R0M-01
SMSC/C-2R0M-01
SMSC/C-3R0M-01
SMSC/C-6R0M-01
SMSC/C-100M-01
SMSC/C-230M-01
SMSC/C-500M-01
SMSC/C-700M-01
SMSC/C-161M-01
1
2
3
6
10
23
50
70
160
F
L
(MHZ)
1.0
1.0
1.0
1.0
1.0
0.10
0.10
0.10
0.10
Tol.
(%)
±
20
±
20
±
20
±
20
±
20
±
20
±
20
±
20
±
20
Current
(A)
6.00
4.00
3.00
2.00
1.50
0.70
0.40
0.35
0.15
Resistance
(m
Ω
)
11
20
38
120
230
730
3000
4500
18000
Material
28
I r o n O xi d e
MISC/C, SMSC/C & 77A/C
Suppression Inductors
Technical Data
1. Rated
inductance:
Measured at:
1 MHz for
1 0 0 K H z f o r 1 0
µH
1 0 K H z f o r 1 0 0 0
µH
500V, AC
L
≤
<
L
≤
<
L
≤
1 0
µH
1 0 0 0
µH
1 0 0 0 0
µH
4. DC-Resistance:
Measured at 25
°
C
2. Rated voltage:
5. Dielectric
strength:
2 . 5 K V ( wi t h i n s u l a t i o n
material)
3. Rated current:
Based on a temperature rise; determined
a s a p o i n t wh e r e t h e t e m p e r a t u r e r i s e d o e s
n o t e xc e e d 4 0
°
C a b o v e t h e a m b i e n t
temperature of 25
°
C
6. Operating
temperature
IEC Climatic category
55/125/56
DIN climatic category FKF
- 55
°
C to 125
°
C, humidity
category F
Delivery Form & Taping Specification
91
9.0
10
Pitch Dimension
Series
P min
P min(mm)
MISC/
C
17.5
SMSC/C
22.5
77A/C
29.5
(33.5*)
* only valid for 77A-3R9M-00
Ordering Code
MISC/C - 1RO M - 00
Type
-00- Loose packing
-01- Taped on Reel
Delivery
Tolerance
Nominal
Example: MISC/C-1ROM-00 denotes miniature
suppression coil with foil protection.
1µH
±
20% axial, loose packaging.
26
