200W TRC-200 Dimmable Series
Switch Mode LED Drivers
Constant Current
Aluminum Housing
Electrical Specifications
Input Voltage Range:
Frequency:
Power Factor:
Inrush Current:
Input Current:
Maximum Power:
Line Regulation:
Load Regulation:
Leakage Current:
Typical Efficiency
Turn-on Delay:
Ripple and Noise:
Protection:
100 - 277 Nom. Vax (90 - 305 V Min/Max)
50/60 Hz Nom. (47-63 Hz Min/Max)
>0.90 @ full load, 100V through 277V
65 Amps max @ 230 Vac, cold start 25ºC
2.4 A max 100Vac, 1.2 A max 220Vac
200W
± 1%
± 3%
0.75 mA max @ 277 Vac 60Hz
92.5%-93.5% at 220Vac
0.5S typical 110Vac, 0.3S typical 220Vac
13.4V at 450 mA
Over-Voltage, Over-Temperature (110°C), Lightning,
and Short Circuit Protection with Self Recovery
Environmental Specifications
Max Case Temperature:
Minimum Starting Temp:
Storage Temperature:
Humidity:
Cooling:
Sound Rating:
MTBF:
Lifetime:
Weight:
90ºC
-35ºC
-40ºC to +85ºC
5% to 100%
Convection
Class A
330,000 Hours (450 mA model) @ 110VAC input, 80%
load and 25ºC ambient conditions per MIL-HDBK-217F,
Other Models 170,000 Hours
64,000 Hours @ 220Vac, 80% load and 45ºC ambient
3.31 lbs. (1.5 kg)
• Total Power: 200 Watts
• Input Voltage: 100-277 Vac Nom.
• UL Dry & Damp Location Rated
• IP67
• Ultra-high Efficiency
• High Power Factor with Active Correction
• UL8750
Dimming Versions - Product Specifications
Model Number
TRC-200S045DT
TRC-200S070DT
TRC-200S105DT
TRC-200S140DT
Output Current Output Voltage
Max.
Typical
(mA±5%)*
Range
(Vdc)
Output Power
Efficiency
450
700
1050
1400
223-445
143-285
95-190
71-142
200
200
200
200
93.0%
93.0%
92.5%
92.0%
* The output current is adjustable at factory from 50% to 100%.
E332160
Note:
LED drivers are designed and intended to operate LED loads only.
Non-LED loading may be outside the specified design limits of our
LED drivers, and therefore cannot be covered by any warranty.
If you desire to use our LED drivers to operate non-LED loads
please contact us to discuss compatibility.
Specifications subject to change without notice.
Rev 9-1-15
Thomas Research Products • 1225 Bowes Rd • Elgin, IL 60123 • T 847-515-3057 • F 847-515-3047 • www.trpssl.com
TRC-200 Dimming Series
SSL Solutions Faster Than The Speed Of Light
®
Pg 2 of 3
AC INPUT (UL SJTW, 3*AWG #18)
Black (ACL)
White (ACN)
Green (GND)
239
235
310±20
Dimming Control Wire
(UL2464, 2*AWG #22)
Purple (Dim+)
Gray (Dim-)
46
39.5
65±5
10±2
50±5
28.58
50±5
15±2
Tc = 90°C max
650±20
135.76
DC OUTPUT
(UL SJTW, 2*AWG #18)
Red (V+)
Blue (V-)
230±20
50
34
8
5
5
250
253
266
Derating Curve
100
80
Derating Curve
100
80
Load
(%)
60
40
20
0
-35
100Vac
277Vac
Load
(%)
60
40
20
0
90
-20
Ambient Temperature
(°C)
-5
10
25
40
55
70
120
150
Input Voltage
(V)
180
39.5
46
210
240
270
300
15±2
50±5
330
300
250
Lifetime / Case Temperature
(450mA)
500
400
300
200
100
0
Lifetime / Case Temperature
(1400mA)
UL/CUL
CE
EN 55015
EN 61000-3-2
EN 61000-3-3
EN 61000-4-2
EN 61000-4-3
EN 61000-4-4
30
40
50
60
70
80
90
Safety and EMC Compliance
UL8750, UL1012, UL935, CSA-C22.2 No. 107.1-01
EN 61347-1, EN61347-2-13
Conducted emission
Harmonic current emissions
Voltage fluctuations and flicker
Electrostatic discharge
RFE Field Susceptibility test
Electrical Fast Transient
Surge Immunity test
Conducted Radio Frequency
Power Frequency Magnetic Field Test
Voltage Dips
Electromagnetic Immunity
Lifetime
(kHrs)
200
150
100
50
0
30
40
50
60
70
80
90
Lifetime
(kHrs)
Case Temperature
(°C)
Case Temperature
(°C)
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
EN 61000-4-11
EN 61547
Thomas Research Products • 1225 Bowes Rd • Elgin, IL 60123 • T 847-515-3057 • F 847-515-3047 • www.trpssl.com
67.5
79.5
TRC-200 Dimming Series
SSL Solutions Faster Than The Speed Of Light
®
Pg 3 of 3
Dimming Control (on secondary side)
Parameters
Absolute maximum voltage on the 0-10V input pin
Source current on 0-10V input pin
Minimum
-2 V
0 µA
Typical
—
—
Maximum
12 V
1 mA
The dimmer control is operated from an input signal of 1 – 10 Vdc. Recommended implementations are provided below.
Vcc
Rin
Normalized Output Current
Option 1 - DC Input
Output Current / Dimming Voltage
100%
80%
60%
40%
20%
0%
1-10V Input (Purple)
1-10Vdc
V
GND (Gray)
TRC-200xxxDT
0
1
2
3
4
Vdim
(V)
5
6
7
8
9
10
Option 2 - External Resistor
Vcc
Rin
Output Current / Rx
Normalized Output Current
100%
80%
60%
40%
20%
0%
1-10V Input (Purple)
Rx
GND (Gray)
TRC-200xxxDT
0
20
40
60
80
Rx
(kΩ)
10
120 140 160 180 200 220
Notes:
1. Io is actual output current and Ir is rated current without dimming control.
2. For the driver to operate properly, the load voltage must be maintained above the minimum voltage
threshold (approx. 50% of the max. output voltage for any given model).
3. If the output voltage is maintained above 50% of the maximum output voltage, the dimming control may
be operated over the entire 1-10V range with output current varying from 10% to 100% of Ir.
4. The dimming input signal may be less than 1V; however, no further dimming will occur between 0V and 1V.
5. The internal resistor Rin is 20K, and Vcc is about 15V.
6. Do not connect the GRAY of dimming to the output; otherwise, the LED driver can not work normally.
Thomas Research Products • 1225 Bowes Rd • Elgin, IL 60123 • T 847-515-3057 • F 847-515-3047 • www.trpssl.com
