PD-91887E
SCHOTTKY RECTIFIER
HIGH EFFICIENCY SERIES
8CLJQ045
8Amp, 45V
Description/Features
A
V
A
V
°C
The 8CLJQ045 center tap Schottky rectifier has
been expressly designed to meet the rigorous
requirements of HiRel environments.It is packaged
in the hermetic surface mount SMD-0.5 ceramic
package. The device's forward voltage drop and
reverse leakage current are optimized for the
lowest power loss and the highest circuit efficiency
for typical high frequency switching power
supplies and resonent power converters. Full MIL-
PRF-19500 quality conformance testing is
available on source controlled drawings to TX, TXV
and S levels.
Hermetically Sealed
Center Tap
Low Forward Voltage Drop
High Frequency Operation
Guard Ring for Enhanced Ruggedness
and Long Term Reliability
• Surface Mount
• Lightweight
•
•
•
•
•
Major Ratings and Characteristics
Characteristics
I
F(AV)
Rectangular Waveform
V
RRM
(Per Leg)
I
FSM
@ tp = 8.3ms half-sine
(Per Leg)
V
F
@ 4Apk, T
J
= 125°C
(Per Leg)
T
J
, T
STG
Operating and Storage -55 to 150
0.58
8CLJQ045 Units
8
45
80
CASE STYLE
( ISOLATED BASE )
2
1
3
ANODE COMMON ANODE
CATHODE
Case Outline and Dimensions - SMD-0.5
www.irf.com
1
03/04/15
8CLJQ045
Voltage Ratings
Part number
V
R
Max. DC Reverse Voltage (V) (Per Leg)
V
RWM
Max. Working Peak Reverse Voltage (V) (Per Leg)
8CLJQ045
45
Absolute Maximum Ratings
Parameters
I
F(AV)
Max. Average Forward Current
See Fig. 5
I
FSM
Max. Peak One Cycle Non-Repetitive
Surge Current (Per Leg)
80
A
@ t
p
= 8.3 ms half-sine
Limits
8.5
Units
A
Conditions
50% duty cycle @ T
C
= 100°C, rectangular waveform
Electrical Specifications
Parameters
V
FM
Max. Forward Voltage Drop
(Per Leg) See Fig. 1
Limits
0.72
0.97
0.67
0.96
0.58
0.92
Units
V
V
V
V
V
V
mA
mA
pF
nH
@ 4A
@ 8A
@ 4A
@ 8A
@ 4A
@ 8A
Conditions
T
J
= -55°C
T
J
= 25°C
T
J
= 125°C
V
R
= rated V
R
I
RM
C
T
L
S
Max. Reverse Leakage Current
(Per Leg) See Fig. 2
Max. Junction Capacitance (Per Leg)
Typical Series Inductance (Per Leg)
0.15
43
760
4.8
T
J
= 25°C
T
J
= 125°C
V
R
= 5V
DC
( 1MHz, 25°C )
Measured from center of cathode pad to center of
anode pad
Thermal-Mechanical Specifications
Parameters
T
J
T
stg
Max.Junction Temperature Range
Max. Storage Temperature Range
to Case (Per Leg)
R
thJC
Max. Thermal Resistance, Junction
to Case (Per Package)
wt
Weight (Typical)
Die Size
Case Style
Pulse Width < 300µs, Duty Cycle < 2%
1.0
60X60
SMD-0.5
g
mils
1.86
°C/W
DC operation
Limits Units
-55 to 150
-55 to 150
3.73
°C
°C
°C/W
DC operation
Conditions
R
thJC
Max. Thermal Resistance, Junction
See Fig. 4
2
www.irf.com
8CLJQ045
100
Reverse Current - I
R
(mA)
T = 150°C
10
J
100
125°C
100°C
1
75°C
50°C
25°C
A
0
10
20
30
40
50
0.1
0.01
F
(A)
0.001
Instantaneous Forward Current - I
Reverse Voltage - V
R
(V)
Fig. 2 - Typical Values of Reverse Current
Vs. Reverse Voltage (Per Leg)
10
J
J
T
J
= 25°C
T
J
= -55°C
1
0.0
0.5
1.0
1.5
2.0
Forward Voltage Drop - V
FM
(V)
Fig. 1 - Max. Forward Voltage Drop Characteristics
(Per Leg)
Junction Capacitance - C
T
= 125°C
T
(pF)
T
= 150°C
1000
T
J
= 25°C
100
0
10
20
30
40
A
50
Reverse Voltage - V
R
(V)
Fig. 3 - Typical Junction Capacitance Vs.
Reverse Voltage (Per Leg)
www.irf.com
3
8CLJQ045
10
Thermal Response (Z
thJC
)
D = 0.50
1
0.20
0.10
0.05
0.02
0.01
SINGLE PULSE
(THERMAL RESPONSE)
P
DM
t
1
t
2
Notes:
1. Duty factor D = t
1
/ t
2
2. Peak T
J
= P
DM
x Z
thJC
+ T
C
0.0001
0.001
0.01
0.1
1
0.1
0.01
0.00001
t
1
, Rectangular Pulse Duration (sec)
Fig. 4 - Max. Thermal Impedance Z
thJC
Characteristics (Per Leg)
180
160
140
120
100
80
60
40
20
0
0
2
4
6
8
10
12
Allowable Case Temperature - (°C)
8CLJQ045
8CLQ045
R
(DC) = 3.73°C/W
thJC
thJC
(DC) = 1.86°C/W
R
DC
A
Average Forward Current - I
F(AV)
(A)
Fig. 5 - Max. Allowable Case Temperature Vs.
Average Forward Current
IR WORLD HEADQUARTERS:
101 N. Sepulveda Blvd., El Segundo, California 90245, USA Tel: (310) 252-7105
IR LEOMINSTER :
205 Crawford St., Leominster, Massachusetts 01453, USA Tel: (978) 534-5776
TAC Fax: (310) 252-7903
Visit us at www.irf.com for sales contact information
.
Data and specifications subject to change without notice. 03/2015
