SCHOTTKY DIE SPECIFICATION
Product Name: BWS-60-40-SA
General Description:
SYM
VBRM
IFAV
VF MAX
60mil
40V
Standard VF
UNIT
Volt
Amp
Volt
ELECTRICAL CHARACTERISTICS
Reverse Breakdown Voltage: Ir=0.20mA
Average Rectified Forward Current
Maximum Instantaneous Forward Voltage
@ 5 Amperes, Ta=25℃
Maximum Instantaneous Reverse Current
VR= 43
Volt, Ta=25℃
MAXIMUM RATINGS
Nonrepetitive Peak Surge Current
Semi-Sine Wave, Duty = 8.3ms、1cycle
Operating Junction Temperature
Storage Temperatures
Spec. Limit
45
5.0
0.50
IR MAX
0.100
mA
IFSM
Tj
TSTG
150
125
-55 to +125
Amp
℃
℃
BW does not
1. Specification is applied to die only. Actual performance may degrade when assembled.
guarantee device performance after assembly.
2. Suggest to storage in Nitrogen cabinet, 45-60% RH, 22-26
℃
for 6 months.
3. Data sheet information is subjected to change without notice.
4. Suggest Soldering profile (Pb92.5%,5%Sn,Ag2.5%): Soldering peak Temp. 320~350
℃
3~5min.
DICE
OUTLINE
DRAWING
DIM
A
B
C
Die Size
ITEM
μ
m
1524
1324
280
Mil
60.00
52.13
11.00
Top Metal Pad Size
Thickness
(1)Cutting street width is around 20µm.
(2)Top-side is Ti/Al and back-side metal is Ti/Ni/Ag.
(3) Top-side Ti/Ni thk: 0.42um, Ag thk: 3.5um
