UMZ-575-D16-G: DescriptionMICROSTRIP VOLTAGE CONTROLLED; File Size255KB，3 Pages; ManufacturerRF Micro Devices (Qorvo)

Download Datasheet View All

UMZ-575-D16-G Overview

MICROSTRIP VOLTAGE CONTROLLED

Preview

Download Datasheet

View All

UMZ-575-D16-

MICROSTRIP

Voltage con-

trolled oscilla-

tor

UMZ-575-D16-G

MICROSTRIP VOLTAGE CONTROLLED

OSCILLATOR

Package: D16, 12.7mm x 12.7mm x 5.59mm

Features



Ultra-Linear Tuning/Low Phase

Noise

Frequency: 800Hz to 950Hz

Resonator: Microstrip

PCB: Rogers

Package Size: 12.7mm x

12.7mm x 5.59mm (0.5in x 0.5in

x 0.22in)

TUNE

Tank Circuit



Resonator

Active

Circuit

RF Output

Voltage Controlled Oscillator (VCO)

Applications



Frequency Synthesizers

Up & Down Converters

Instrumentation

Wideband Frequency

Applications

Functional Block Diagram

Product Description

This series of VCO modules offers ultra-linear tuning across their specified fre-

quency band.

Ordering Information

UMZ-575-D16-G

Optimum Technology Matching® Applied

GaAs HBT

GaAs MESFET

InGaP HBT

SiGe BiCMOS

Si BiCMOS

SiGe HBT



GaAs pHEMT

Si CMOS

Si BJT

GaN HEMT

BiFET HBT

LDMOS

RF MICRO DEVICES®, RFMD®, Optimum Technology Matching®, Enabling Wireless Connectivity™, PowerStar®, POLARIS™ TOTAL RADIO™ and UltimateBlue™ are trademarks of RFMD, LLC. BLUETOOTH is a trade-

mark owned by Bluetooth SIG, Inc., U.S.A. and licensed for use by RFMD. All other trade names, trademarks and registered trademarks are the property of their respective owners. ©2006, RF Micro Devices, Inc.

DS120109

7628 Thorndike Road, Greensboro, NC 27409-9421 · For sales or technical

support, contact RFMD at (+1) 336-678-5570 or customerservice@rfmd.com.

1 of 3
