TWC-14-A-2080-S-K-2 datasheet, PDF

Datasheet> All Categories > Wireless rf/communication> Optical fiber> TWC-14-A-2080-S-K-2

TWC-14-A-2080-S-K-2: DescriptionSplitter/Coupler, 1535nm Min, 1570nm Max, 1X4 Port, 80/20 Ratio, FC/APC Connector; CategoryWireless rf/communication Optical fiber; File Size218KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

TWC-14-A-2080-S-K-2 Overview

Splitter/Coupler, 1535nm Min, 1570nm Max, 1X4 Port, 80/20 Ratio, FC/APC Connector

TWC-14-A-2080-S-K-2 Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknown
Other features	ALSO OPERATES AT 1490NM WAVELENGTH
Connection Type	FC/APC CONNECTOR
Fiber optic equipment types	SPLITTER/COUPLER
Fiber type	SMF-28
Maximum insertion loss	3.8 dB
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum operating wavelength	1570 nm
Minimum operating wavelength	1535 nm
Nominal operating wavelength	1553 nm
Port configuration	1X4
Split ratio/coupling ratio	80/20

Preview

Download Datasheet

View All

FBT COUPLER

Three Window Wideband Coupler

(Based on 50/50)

Parameter

Operating Wavelength Range

Insertion Loss

Uniformity

Return Loss

PDL

TDL

Operating & Storage Temperature

Light Duty ( B )

Package Dimensions

Medium Duty ( L )

Heavy Duty (K, R)

Premium

A grade

1260-1360 nm, 1480-1500 nm, 1535-1570 nm

≤ 3.6 dB

≤ 0.7 dB

≤ 3.8 dB

≤ 1.0 dB

≥ 55 dB (1x2) ≥ 65 dB (2x2)

≤ 0.15 dB

≤ 0.2 dB

≤ 0.2 dB (- 10° C ~ + 75° C) ≤ 0.35 dB (- 40° C ~ + 85° C)

- 40° C ~ + 85° C

3.0mm (

) x 55.0mm (L)

3.0mm (

) x 60.0mm (L)

100.0 mm x 12.0 mm x 8.0 mm

Tap Coupler

Coupling Ratio

40/60

30/70

20/80

10/90

5/95

1/99

Premium

4.7 / 2.7 dB

6.0 / 1.9 dB

7.9 / 1.2 dB

11.3 / 0.6 dB

15.0 / 0.4 dB

23.5 / 0.3 dB

A Grade

5.0 / 2.5 dB

6.4 / 2.2 dB

8.5 / 1.4 dB

12.7 / 0.8 dB

16.0 / 0.5 dB

25.0 / 0.4 dB

Tree Coupler

Max IL

Uniformity

Premium A Grade Premium

A Grade

1x4

7.2 dB

7.6 dB

1.3 dB

1.8 dB

1x8

11.0 dB

11.3 dB

2.0 dB

2.4 dB

1 x 16

14.4 dB

15.2 dB

2.7 dB

3.2 dB

1 x 32

18.1 dB

19.0 dB

3.4 dB

4.2 dB

* Other port numbers upon request

Port #

Note1: All values specified are without connectors.

Note2: Higher performance specifications upon request.

Note3: Fiber type Corning SMF-28e.

T WC

Port Number

12: 1 x 2

14: 1 x 4

18: 1 x 8

16: 1 x 16

32: 1 x 32

Grade

P: Premium

A: A Grade

Coupling Ratio

xy%:xy%

Fiber Length

1: 1 meter

2: 2 meter

S: Special

Pigtail Style

(=Package style)

B: bare fiber

L: 900

µm

loose tube

K: 2 mm cable

R: 3 mm cable

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

www.lighteltech.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax
