CLV1225A-LF
PHASE NOISE (1 Hz BW, typical)
14118 Stowe Drive, Suite B
Poway, CA 92064
TEL: (858) 621-2700 | FAX: (858) 486-1927
URL: www.zcomm.com
EMAIL: applications@zcomm.com
Rev B2
Applications
• Digital Radios
• Satellite Communications
• Basestations
Application Notes
• AN-101: Mounting and Grounding
• AN-102: Output Loading
• AN-107: Manual Soldering
OFFSET (Hz)
Performance Specifications
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW)
Harmonic Suppression (2nd)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance
Pushing
Pulling (14 dB Return Loss, Any Phase)
Operating Temperature Range
Package Style
£(f) (dBc/Hz)
Voltage-Controlled Oscillator
Surface Mount Module
Min
1180
Typ
-109
-25
Max
1270
-16
4.5
Units
MHz
dBc/Hz
dBc
Vdc
MHz/V
dBm
pF
MHz/V
MHz
°C
0.5
37
-1
2.5
50
6
50
1
1
-40
MINI-14S-L
85
Power Supply Requirements
Supply Voltage (Vcc, nom.)
Supply Current (Icc)
Min
Typ
5
26
Max
31
Units
Vdc
mA
Additional Notes
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 1 of 2
FRM-S-002 B
Voltage-Controlled Oscillator
Surface Mount Module
Tuning Curve, typ.
1330
1310
CLV1225A-LF
Rev B2
FREQUENCY (MHz)
1290
1270
1250
1230
1210
1190
1170
1150
1130
1110
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
85 °C
25 °C
-40 °C
TUNING VOLTAGE (Vdc)
Power Curve, typ.
POWER OUTPUT (dBm)
RECOMMENDED FOOTPRINT
8
7
6
5
4
3
2
1
0
-1
-2
1131
1156
1177
1197
1217
1236
1256
1275
1295
1315
Footprint
SEVERAL HOLES OF O 0.015 ON
GND. PLANE ARE RECOMMENDED
FOR GOOD GROUNDING.
0.030 MIN. CUTBACK
FROM LIVE PADS
FREQUENCY (MHz)
85 °C
25 °C
-40 °C
Physical Dimensions
PIN CONFIGURATION
Z-COMM
XXXXXXXX-LF
W/O#
D/C
P1
P2
P3
REST
Vt
RF OUT
Vcc
GROUND
PACKAGE
MINI-14S
MINI-14S-L
H
0.220
0.130
MINI-14S-LOW 0.160
NOTE: ALL DIMENSIONS ARE IN INCHES
TOL: XXX: +/- 0.010
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 2 of 2
FRM-S-002 B
