SAW Filter 678 MHz
MODEL NO.: TA1359A
A. MAXIMUM RATING:
1.Input Power Level: 10 dB
m
2.DC voltage: 5 V
3.Operating Temperature: -30°C to 60°C
4.Storage Temperature: -40°C to +85°C
B. CHARACTERISTICS:
Item
Center frequency, Fc
Amplitude ripple (666 ~ 690 MHz)
Insertion loss, IL (666 ~ 690 MHz)
Group Delay, GD (666 ~ 690 MHz)
Bandwidth @ -3 dB
Attenuation (reference from 0dB)
0.3 ~ 630 MHz
630 ~ 645 MHz
710 ~ 750 MHz
750 ~ 770 MHz
770 ~ 1008 MHz
1008 ~ 1150 MHz
Source impedance, Z
S
Load impedance, Z
L
Unit
MHz
dB
dB
ns
Min.
-
-
-
-
24
30
10
10
30
35
35
-
-
Typ.
678
1.2
2.5
72
43
34
18
29
54
39
38
50
50
Max.
-
1.7
3.0
200
-
-
-
-
-
-
-
-
-
REV. NO.: 1
RoHS Compliant
Lead free
Lead-free soldering
Electrostatic Sensitive Device
(ESD)
dB
dB
dB
dB
dB
dB
Ω
Ω
Note1. No matching network required for operation at 50Ω
TAI-SAW TECHNOLOGY CO., LTD.
TST DCC
Release document
2
D. MEASUREMENT CIRCUIT:
HP Network analyzer
50Ω
B
SAW Filter
E
50Ω
A,C,D,F
E.OUTLINE DRAWING:
1.55
1359
2012
2014
2016
.
a
B : Input
E: Output
A,C,D,F Ground
△:Year
Code
□:
Date Code(Follow the table provided by planner each year.)
Unit: mm
A
