NEW SERIES
LXQ
Series
Snap Mount
Downsize
High Ripple
5,000 Hours
Rated Lifetime
105 C
Maximum
Temperature
Engineering Bulletin Jun 04
Actual Size
The LXQ series is a new high voltage snap-in series that offers higher ripple current capability in
downsized versions of the LXG snap-in capacitors rated from 160 to 450 volts. With the improved
electrical characteristics and the same rated lifetime as the LXG series of 5,000 hours at 105 C with
the rated ripple current applied, the LXQ capacitors are recommended for new designs in place of the
LXG capacitors rated at 160 volts and above. The LXQ capacitors have a standard 2-pin snap-in
terminal style.
The standard LXQ series capacitors are non-solvent proof. Refer to the Mini-Glossary for cleaning
guidelines and recommended cleaning agents that are compatible with United Chemi-Con products.
SNAP MOUNT-105 C
LXQ
Summary of Specifications
PC board 2-pin snap-in terminals.
Capacitance range: 82 to 2,700µF.
Voltage range: 160 to 450VDC.
Category temperature range: 25 C to 105 C.
Leakage current: 3 CV (µA) maximum after 5 minutes at 20 C.
Standard capacitance tolerance: 20%
Nominal case size (D L): 22 25mm to 35 50mm.
Rated lifetime: 5,000 hours at 105 C with the rated ripple current applied.
