ITEM NO.
1
2
3
4
5
PART NUMBER
50-00104
30-00004
24-00017
DESCRIPTION
dc plug, 5.5x2.5xBL12xL30 locking style, brass nickel plated, threaded nut
5/16-32
1C, 18 AWG, UL1185, 300V, 80C, 3.4 mm, shielded, VW-1, PVC, 60P
Holder, plug, 90˚, 6.3 mm, 13 mm, locking
Heat shrink, black,
Heat shrink, black,
4.0 mm, 10 2 mm
2.0 mm, 25 2 mm
QTY.
1
1
1
1
1
NOTES
3.4 mm, 2000 mm
30P, PVC, black
2000 ±50
3
30 ±5
22
10 ±2
5 ±2
16.50
6.50
3.40
6
12 ±0.50
2
1
4
5
5.50
2.50
Wiring diagram
Contact
Center
Sleeve
Wire color
White
Black
Revision
A
Date
10/26/2012
Description
Initial release
RoHS compliant
Notes
Function test: no open, no reversed polarity, no short circuit, no INT
Tensility International Corporation reserves the right to substitute parts
which are functionally equivalent to the ones specified.
DESCRIPTION:
Cable, 2000 mm, 5.5x2.5x12mm 90° 50-00104
locking dc plug to tinned, 18 AWG, UL1185,
30-00004 wire
3
2
20802 Sockeye Place #130
Bend, OR 97701 USA
tel
541.323.3228
fax
541.323.4202
800
877.670.7118 www.tensility.com
SIZE
Part number
A
DIMENSIONS ARE IN MILLIMETERS
TOLERANCES:
X:
0.5 mm
X.X:
0.3 mm
X.XX: 0.05 mm
10-01292
WEIGHT:
1
SHEET 1 OF 1
SCALE: 1:1
5
4
