Operating Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
(at 20°C, 120Hz)
-55~+105°C
4 ~ 50V
0.1 ~ 1000uF
±20% (at 20°C, 120Hz)
I<0.01 CV or 3 uA whichever is greater (at 20°C, after 2 minutes)
I: Leakage Current (uA)
C: Nominal Capacitance (uF)
V: Rated Voltage (V)
Rated Voltage (V)
tanδ
W.V
Z(-25°C)/Z(+20°C)
Z(-40°C)/Z(+20°C)
4
0.35
4
7
15
6.3
0.26
6.3
4
6
10
0.20
10
3
4
16
0.16
16
2
4
25
0.14
25
2
4
35
0.12
35
2
3
50
0.12
50
2
3
Temperature Characteristics
(Impedance Ratio at 120Hz)
The following specification shall be satisfied when the capacitors are restored to 20°C after the rated
working voltage ia applied for 1000 hours at maximum operating temperature.
Load Life (+105°C)
Capacitance Change
Dissipation Factor
Leakage Current
Within± 20% of the initial value
200% of the specified value or less
The specified value or less
Shelf Life (+105°C)
Test Conditions:
Duration Time: 1000 hours
Ambient Temperature: + 105°C
Applied Voltage: None
After Test Requirement at +20°C: Same limits as Load Life
Pre-treatment for measurements shall be conducted after DC working voltage applied for 30 minutes
Place terminal side surface on 250°C hot plate for 30 seconds allowing test samples to cool down to
room temperature
Capacitance Change
Dissipation Factor
Leakage Current
Within± 10% of the initial value
The specified value or less
The specified value or less
Soldering Heat Resistance
ΦD
3
4
5
6.3
6.3
6.3
8
L
5.7
5.7
5.7
5.7
6.0
7.7
10.5
A
3.3
4.3
5.3
6.6
6.6
6.6
8.3
B
3.3
4.3
5.3
6.6
6.6
6.6
8.3
C
1.5
1.8
2.2
2.4
2.4
2.4
2.9
W
0.45~0.75
0.5~0.8
0.5~0.8
0.5~0.8
0.5~0.8
0.5~0.8
0.7~1.0
P
0.6
1.0
1.5
2.2
2.2
2.2
3.2
Embedded System
