1N5913B - 1N5957B
1.5 Watts Axial Leaded Zener Diodes
Features
·
·
·
·
Complete Voltage Range 3.3 to 200 Volts
High peak reverse power dissipation
High reliability
Low leakage current
A
B
A
D
C
Mechanical Data
·
Case : DO-41 Molded plastic
·
Epoxy : UL94V-O rate flame retardant
·
Lead : Axial lead solderable per MIL-STD-202,
method 208 guaranteed
·
Polarity : Color band denotes cathode end
·
Mounting position : Any
·
Weight : 0.335 gram
DO-41
Dim
A
B
C
D
Min
25.40
4.06
0.71
2.00
Max
¾
5.21
0.864
2.72
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
@ T
A
= 25°C unless otherwise specified
Rating
Maximum Steady state Power Dissipation
@ T
L
= 75 ºC, Lead Length = 3/8"
Derate above 75 ºC
Symbol
P
D
Value
1.5
Unit
W
15
mW/ ºC
Peak forward Surge Current 8.3ms single half sine-wave
superimposed on rated load(JEDEC Method) (Note 1,2)
Operating and Storage Temperature Range
I
FSM
T
J
,T
STG
10
- 65 to + 200
Amps
°C
1 of 2
