MZ85C3V0~MZ85C200
1.3 Watts Axial Leaded Zener Diodes
Features
·
Complete Voltage Range 3.0 to 200 Volts
·
High peak reverse power dissipation
·
High reliability
·
Low leakage current
·
Pb / RoHS Free
D
A
B
A
C
Mechanical Data
·
Case : DO-41 Molded plastic
·
Epoxy : UL94V-O rate flame retardant
·
Lead : Axial lead solderable per MIL-STD-202,
method 208 guaranteed
·
Polarity : Color band denotes cathode end
Mounting position : Any
·
Weight : 0.20 gram (approximately)
DO-41
Dim
A
B
C
D
Min
25.40
4.06
0.71
2.00
Max
¾
5.21
0.864
2.72
All Dimensions in mm
Maximum Ratings
@ T
A
= 25°C unless otherwise specified
.
Rating
DC Power Dissipation at T
L
= 50 °C (Note1)
Maximum Forward Voltage at I
F
= 200 mA
Symbol
P
D
V
F
R
ӨJA
T
J
T
STG
Value
1.3
1.2
130
- 65 to + 200
- 65 to + 200
Unit
W
V
K/W
°C
°C
Maximum Thermal Resistance Junction to Ambient Air (Note2)
Junction Temperature Range
Storage Temperature Range
Notes :
(1) T
L
= Lead temperature at 3/8 " (9.5mm) from body
(2) Valid provided that leads are kept at ambient temperature at a distance of 10 mm from case.
Fig. 1 POWER TEMPERATURE DERATING CURVE
1.5
P
D
, MAXIMUM DISSIPATION
(WATTS)
L = 3/8" (9.5mm)
1.2
0.9
0.6
0.3
0
25
50
75
100
125
150
175
200
T
L,
LEAD TEMPERATURE (
°
C)
1 of 2
