o
Part Numbering
Radial Lead Type Monolithic Ceramic Capacitors
(Part Number)
qProduct
ID
wSeries/Terminal
Product ID
RP
Series/Terminal
E
Radial Lead Type Monolithic
Ceramic Capacitors
RP
q
E
w
R7 1H
e
r
104
t
K
2
M1
i
A03 A
o
!0
y u
eTemperature
Characteristics
Code
5C
E4
F5
R7
rRated
Voltage
Code
1E
1H
2A
tCapacitance
Expressed by three figures. The unit is pico-farad (pF). The first
and second figures are significant digits, and the third figure
expresses the number of zeros which follow the two numbers.
If there is a decimal point, it is expressed by the capital letter "R".
In this case, all figures are significant digits.
yCapacitance
Tolerance
Code
C
D
J
K
M
Z
Capacitance Temperature
Tolerance Characteristics
±0.25pF
±0.5pF
±5%
±10%
±20%
+80%, -20%
X7R
Z5U
Y5V
C0G
Capacitance
Step
V5pF
: 1pF Step
6 to 9pF : 1pF Step
U10
: E12 Series
E6 Series
E3 Series
E3 Series
!0
Packaging
Code
A
B
uDimensions
(LxW)
Code
1
2
3
4
5
6
7
8
Dimensions (LxW)
3.5g3.0mm
5.0g3.5mm
5.0g4.5mm
7.5g5.0mm
7.5g7.5mm
10.0g10.0mm
12.5g12.5mm
7.5g5.5mm
Packaging
Ammo Pack
Bulk
Rated Voltage
DC25V
DC50V
DC100V
Temperature
Characteristics
C0G
Z5U
Y5V
X7R
Temperature
Range
25 to 125°C
10 to 85°C
-30 to 85°C
-55 to 125°C
iLead
Style
Code
A1
B1
C1
E1/E2
K1
M1/M2
P1
S1/S2
Lead Style
Straight Long
Straight Long
Straight Long
Straight Taping
Inside Crimp
Inside Crimp Taping
Outside Crimp
Outside Crimp Taping
Lead Spacing
F=2.5mm
F=5.0mm
other than above
F=5.0mm
F=5.0mm
F=5.0mm
F=2.5mm
F=2.5mm
Capacitance Change or
Temperature Coefficient
0±30ppm/°C
+22, -56%
+22, -82%
±15%
Operating
Temperature Range
-55 to 125°C
10 to 85°C
-30 to 85°C
-55 to 125°C
Lead distance between reference and bottom planes.
M1, S1 : H
0
= 16.0±0.5mm
M2, S2 : H
0
= 20.0±0.5mm
E1 : H = 17.5±0.5mm
E2 : H = 20.0±0.5mm
oIndividual
Specification Code
Expressed by three figures
2
Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
!Note
•Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this PDF catalog to prevent smoking and/or burning, etc.
•This catalog has only typical specifications. Therefore,thereareno space for detailed specifications. Therefore, please approve our productsheet for product specifications before ordering. product specifications before ordering.
This catalog has only typical specifications because you is requested to approve our product specifications or to transact the approval specifications or transact the approval sheet for
C49E15.pdf 04.12.29
Radial Lead Type Monolithic Ceramic Capacitors
Radial Lead Type Monolithic Ceramic Capacitors
L max.
T max.
1
s
Features
1. The RPE series capacitors have small dimensions,
large capacitance, and a capacity volume ratio of
10 micro F/cm cube, close to that of electrolytic
capacitors. These do not have polarity.
2. These have excellent frequency characteristics and
due to these small internal inductance are suitable
for high frequencies.
3. These are not coated with wax so there is no change
in their exterior appearance due to the outflow of
wax during soldering or solvent during cleansing.
4. These are highly inflammable, having
characteristics equivalent to the UL94V-0 standard.
L max.
W max.
T max.
1.5 max.
W max.
25.0 min.
F : 2.5±0.8
ød : 0.4±0.05
Dimensions code: 1
Lead style code: A1
· Lead Wire : Solder Coated Copper Wire or
Solder Coated CP Wire
(in mm)
L max.
W max.
T max.
W1 max.
∗
25.0 min.
25.0 min.
F : 5.0±0.8
ød : 0.5±0.05
ød : 0.5±0.05
F : 2.5±0.8
Dimensions code: 2/3
Lead style code: P1
∗
Coating extension does not exceed the end of the lead bend.
· Lead Wire : Solder Coated Copper Wire or
(in mm)
Solder Coated CP Wire
Dimensions code: 2/3/4/8
Lead style code: K1
∗
Coating extension does not exceed the end of the lead bend.
· Lead Wire : Solder Coated Copper Wire or
(in mm)
Solder Coated CP Wire
L max.
1.5 max.
W max.
T max.
s
Dimensions
Dimensions and
Lead style code
1A1
2P1/2S1/2S2
2K1/2M1/2M2
3P1/3S1/3S2
3K1/3M1/3M2
4K1/4M1/4M2
5B1/5E1/5E2
6B1/6E1/6E2
7C1
8K1/8M1/8M2
TB1/TE1/TE2
Dimensions (mm)
W1
T
F
-
2.5
5.0
2.5
5.0
5.0
6.3
2.5
See
6.3
5.0
the individual
7.0
5.0
product
-
5.0
specification
-
5.0
-
10.0
8.0
5.0
-
5.0
ød : 0.5±0.05
F±0.8
Dimensions code: 5/6/7
Lead style code: B1/C1
· Lead Wire : Solder Coated Copper Wire or
Solder Coated CP Wire
(in mm)
L
3.5
5.0
5.0
5.0
5.0
7.5
7.5
10.0
12.5
7.5
10.0
W
3.0
3.5
3.5
4.5
4.5
5.0
7.5
10.0
12.5
5.5
8.5
W1 max.
∗
d
0.4
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
25.0 min.
Continued on the following page.
3
Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
!Note
•Please read rating and
!CAUTION
(for storage, operating, rating, soldering, mounting and handling) in this PDF catalog to prevent smoking and/or burning, etc.
•This catalog has only typical specifications. Therefore,thereareno space for detailed specifications. Therefore, please approve our productsheet for product specifications before ordering. product specifications before ordering.
This catalog has only typical specifications because you is requested to approve our product specifications or to transact the approval specifications or transact the approval sheet for
C49E15.pdf 04.12.29
Continued from the preceding page.
1
s
Marking
Type
Dimensions
Code
1
Temp. Char.
Temperature Compensating Type
C0G
X7R
High Dielectric Constant Type
Z5U
Y5V
Individual
Specification
Code
App
Bpp
Zpp
2
Individual
Specification
Code
Except
App
Bpp
Zpp
102J
5A
222K
222M
224Z
Marked on both sides
M
682
J5A
M
224
K5C
M
224
M5E
M
474
Z5F
M
103
M
684
M
105
M
105
3, 4, 8
J5A
K5C
M5E
Z5F
M
M
M
M
5, 6, 7
333
J5A
225
K5C
225
M5E
225
Z5F
Temperature Characteristics
Nominal Capacitance
Capacitance Tolerance
Rated Voltage
Manufacturer's Identification
Marked with code (C0G char.: A, X7R char.: C, Z5U char.: E, Y5V char.: F)
