11DQ03-11DQ10
1.0A Axial Leaded Schottky Barrier Rectifier Diodes
Features
·
·
·
·
·
·
·
·
High current capability
High surge current capability
High reliability
High efficiency
Low power loss
Low forward voltage drop
Low cost
Pb / RoHS Free
A
B
A
D
C
Mechanical Data
·
Case : DO-41 Molded plastic
·
Epoxy : UL94V-O rate flame retardant
·
Lead : Axial lead solderable per MIL-STD-202,
Method 208 guaranteed
·
Polarity : Color band denotes cathode end
·
Mounting position : Any
·
Weight : 0.339 gram
Dim
A
B
C
D
DO-41
Min
25.40
4.06
0.71
2.00
Max
¾
5.21
0.864
2.72
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
@ T
A
= 25°C unless otherwise specified
RATING
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Current
Maximum Peak Forward Surge Current
single half sine wave superimposed on rated load
Maximum Forward Voltage
at I
F
= 1 A, T
J
= 25°C
at I
F
= 2 A, T
J
= 25°C
Maximum Reverse Current at
Rated DC Blocking Voltage
Junction Temperature Range
Storage Temperature Range
T
J
= 25°C
T
J
= 125°C
SYMBOL 11DQ03 11DQ04 11DQ05 11DQ06 11DQ09 11DQ10 UNIT
V
RRM
V
RMS
V
DC
I
F(AV
)
T
C
I
FSM
75
42
0.55
0.71
I
R
I
R(H)
T
J
T
STG
1.0
6.0
30
21
30
40
28
40
50
35
50
1.1
84
26
0.58
0.76
1.0
11
- 40 to + 150
- 40 to + 150
75
42
0.85
0.96
0.5
1.0
mA
°C
°C
60
42
60
90
63
90
100
70
100
V
V
V
A
°C
A
V
F
V
1 of 2
RATING AND CHARACTERISTIC CURVES ( 11DQ03 - 11DQ10 )
FIG.1 - FORWARD CURRENT DERATING CURVE
1.2
FIG.2 - MAXIMUM FORWARD SURGE CURRENT
AVERAGE FORWARD CURRENT,
AMPERES
11DQ03 - 11DQ04
0.8
11DQ05 - 11DQ06
11DQ09 - 11DQ10
PEAK FORWARD SURGE
CURRENT, AMPERES
1.0
50
40
11DQ03 - 11DQ04
11DQ09 - 11DQ10
30
0.6
Square wave (D = 0.50)
80% Rated V
R
applied
0.4
20
11DQ05 - 11DQ06
10
0.2
0
0
25
50
75
100
125
150
175
0
1
2
4
6
10
20
40
60
100
CASE TEMPERATURE, (
°
C)
NUMBER OF CYCLES AT 60Hz
FIG.3 - TYPICAL FORWARD CHARACTERISTICS
20
FIG.4 - TYPICAL REVERSE CHARACTERISTICS
10
FORWARD CURRENT, AMPERES
11DQ03 - 11DQ04
10
11DQ09 - 11DQ10
TJ = 100
°C
REVERSE CURRENT,
MILLIAMPERES
1.0
11DQ05 - 11DQ06
1.0
0.1
TJ = 25
°C
T
J
= 100
°
C
0.01
0
0.1
0.1
20
40
60
80
100
120
140
0.3
0.5
0.7
0.9
1.1
1.3
1.5
1.7
1.9
2.1
PERCENT OF RATED REVERSE
VOLTAGE, (%)
FORWARD VOLTAGE, VOLTS
2 of 2
