Elektronische Bauelemente
DTA123JE/DTA123JUA/DTA123JCA/
DTA123JSA
PNP Digital Transistors (Built-in Resistors)
FEATURES
* Built-in bias resistors enable the configuration of
an inverter circuit without connecting input resistors
(see equivalent circuit).
* Only the on/off confitions need to be set for operation,
making device design easy.
* The bias resistors consis of thin-film resistors with
compete isolation to allow negative biasing of the
input. They also have the advantage of almost
completely eliminating parasitic effects.
PIN CONNENCTIONS AND MARKING
DTA123JE
DTA123JUA
SOT-523
Abbreviated symbol: E32
SOT-323
Abbreviated symbol: 132
DTA123JSA
DTA114ECA
DTA123JCA
TO-92S
SOT-23
Abbreviated symbol: E32
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individual
01-Jun-2002 Rev. A
Page 1 of 2
Elektronische Bauelemente
DTA123JE/DTA123JUA/DTA123JCA/
DTA123JSA
PNP Digital Transistors (Built-in Resistors)
Absolute maximum ratings(Ta=25℃)
Parameter
Supply voltage
Input voltage
Output current
Power dissipation
Junction temperature
Storage temperature
Symbol
V
CC
V
IN
I
O
I
C(MAX)
Pd
Tj
Tstg
150
Limits (DTA123J□
E
UA
-50
-12~+5
-100
-100
200
150
-55~150
300
)
CA
SA
Unit
V
V
mA
mW
℃
℃
Electrical characteristics (Ta=25℃)
Parameter
Input voltage
Output voltage
Input current
Output current
DC current gain
Input resistance
Resistance ratio
Transition frequency
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O(off)
G
I
R
1
R
2
/R
1
f
T
80
1.54
17
2.2
21
250
2.86
26
MHz
KΩ
-1.1
-0.1
-0.3
-3.6
-0.5
Min.
Typ
Max.
-0.5
Unit
V
V
mA
µA
Conditions
V
CC
=-5V, I
O
=-100µA
V
O
=-0.3V, I
O
=-5
mA
I
O
/I
I
=-5mA/-0.25mA
V
I
=-5V
V
CC
=-50V, V
I
=0
V
O
=-5V, I
O
=-10mA
-
-
V
O
=-10V, I
O
=-5mA, f=100MHz
Typical Characteristics
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individual
01-Jun-2002 Rev. A
Page 2 of 2
