DTC113ZE/DTC113ZUA/DTC113ZKA
/DTC113ZCA/DTC113ZSA
Elektronische Bauelemente
Digital Transistors NPN (Built-in Resistors)
FEATURES
* Built-in bias resistors enable the configuration of
an inverter circuit without connecting external
input resistors (see equivalent circuit).
* Only the on/off confitions need to be set for operation
making device design easy.
* The bias resistors consis of thin-film resistors with
compete isolation to allow negative biasing of the
input. They also have the advantage of almost
completely eliminating parasitic effects.
Pin Connenctions And Marking
DTC113ZE
DTC113ZUA
SOT-523
Abbreviated symbol: E21
SOT-323
Abbreviated symbol: E21
DTC113ZKA
DTC113ZCA
DTA113ZCA
SOT-23
SOT-23-3L
Abbreviated symbol: E21
SOT-23
Abbreviated symbol:E21
DTC113ZSA
TO-92S
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individual
01-Jun-2002 Rev. A
Page 1 of 2
DTC113ZE/DTC113ZUA/DTC113ZKA
/DTC113ZCA/DTC113ZSA
Elektronische Bauelemente
Absolute maximum ratings(Ta=25℃)
Parameter
Supply voltage
Input voltage
Output current
Power dissipation
Junction temperature
Storage temperature
Symbol
V
CC
V
IN
I
O
I
C(MAX)
Pd
Tj
Tstg
150
Limits (DTC113Z□)
E
UA
CA
50
-5~+10
100
100
200
150
-55~150
300
mW
℃
℃
KA
SA
Unit
V
V
mA
Digital Transistors NPN (Built-in Resistors)
Electrical characteristics (Ta=25℃)
Parameter
Input voltage
Output voltage
Input current
Output current
DC current gain
Input resistance
Resistance ratio
Transition frequency
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O(off)
G
I
R
1
R
2
/R
1
f
T
33
0.7
8
1
10
250
1.3
12
MHz
V
CE
=10V ,I
E
=-5mA,f=100MHz
KΩ
3
0.3
7.2
0.5
Min.
Typ
Max.
0.3
Unit
V
V
mA
µA
Conditions
V
CC
=5V ,I
O
=100µA
V
O
=0.3V ,I
O
=20 mA
I
O
/I
I
=10mA/0.5mA
V
I
=5V
V
CC
=50V, V
I
=0
V
O
=5V ,I
O
=5mA
Typical Characteristics
